The Bently Nevada 136294-01 is an isolated +4 to +20 mA I/O module with internal terminations designed for processing machine-critical parameters in the 3500 Machinery Protection System. Installed in the rear slot of the 3500 rack directly behind the 3500/62 Process Variable Monitor main module, it accepts up to 6 channels of 4 to 20 mA DC input signals from field transmitters. The 136294-01 provides 500 Volts of galvanic isolation to protect system architecture against ground loops and signal interference while transferring conditioned parameter data to the main monitor board for alarm setpoint evaluation and machinery protection.
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 136294-01 |
| Module Type | Isolated +4 to +20 mA I/O Module with internal terminations |
| Compatible Main Monitor | 3500/62 Process Variable Monitor |
| Signal Input | 4-20 mA DC (6 channels) |
| Isolation | 500 Volts |
| Input Impedance | 50 Ohm |
| Rack Space Requirement | 1 full-height rear slot |
| Operating Temperature (with Internal/External Termination I/O Module) | -30degC to +65degC (-22degF to +149degF) |
| Storage Temperature | -40degC to +85degC (-40degF to +185degF) |
| Humidity | 95%, noncondensing |
| Dimensions (H x W x D) | 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in) |
| Weight | 0.20 kg (0.44 lbm) |
| Certification / Standard | Details |
|---|---|
| cNRTLus (without internal barriers) | Class I, Zone 2: AEx/Ex nA nC ic IIC T4 Gc; Class I, Zone 2: AEx/Ex ec nC ic IIC T4 Gc; Class I, Division 2, Groups A, B, C, and D; T4 @ Ta = -20degC to +65degC (-4degF to +149degF) |
| ATEX / IECEx (without internal barriers) | II 3 G; Ex nA nC ic IIC T4 Gc; Ex ec nC ic IIC T4 Gc; T4 @ Ta = -20degC to +65degC (-4degF to +149degF) |
| EMC Directive | 2014/30/EU; EN 61000-6-2, EN 61000-6-4 |
| LV Directive | 2014/35/EU; EN 61010-1 |
| RoHS Directive | 2011/65/EU |
| China RoHS | EFUP 15 years per SJ/T 11364-2024 |
| Maritime | DNV GL rules for classification; ABS Rules Part 1 |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 136294-01
Country of origin:United States
Product Type: I/O Modules
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 200g
Dimensions: 24.4 mm x 241.3 mm x 99.1 mm (W x H x D)
Shipping port: Xiamen
Warranty: 12 months
