The Bently Nevada 140471-01 is an I/O Module with Internal Terminations designed for signal interfacing within the Bently Nevada 3500 Machinery Protection System. It connects field transducers—such as Proximitor sensors, acceleration sensors, Velomitor sensors, or HTVS—directly to the rear slot of compatible 3500 series monitor modules, including the 3500/42M Proximitor Seismic Monitor and 3500/72M Recip Rod Position Monitor.
The module provides power supply parameters to connected transducers androutes input signals to the main monitor board for signal conditioning, vibration evaluation, position measurement, and alarm setpoint comparison. Equipped with internal termination headers, the 140471-01 accepts direct field wiring without requiring separate external termination blocks.
| Category | Specification | Parameter / Value |
|---|---|---|
| Basic Information | Manufacturer | Bently Nevada |
| Part Number | 140471-01 | |
| Description | I/O Module with Internal Terminations | |
| Physical Specifications | Slot Requirement | 1 full-height rear slot |
| Dimensions (H x W x D) | 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in) | |
| Weight | 0.20 kg (0.44 lb) | |
| Transducer Power Output | Transducer Supply Voltage | -24 Vdc |
| Supply Parameters (Prox / Accel) | Voltage: 23.9 V, Current: 45.5 mA, Power: 1.09 W | |
| Supply Parameters (Velomitor) | Voltage: 23.9 V, Current: 45.5 mA, Power: 1.09 W | |
| Environmental Limits | Operating Temperature | -30 degC to +65 degC (-22 degF to +150 degF) |
| Storage Temperature | -40 degC to +85 degC (-40 degF to +185 degF) | |
| Relative Humidity | 95% non-condensing | |
| Compatible Connector Headers | Standard Euro Style (8-pin, Green) | Part Number 00580434 |
| Standard Euro Style (3-pin, Green) | Part Number 00580441 | |
| Push-in-spring Type | Part Number 166M2389 (Alternative to 00580434) | |
| Push-in-spring Type | Part Number 166M4363 (Alternative to 00580441) |
| Certification / Standard | Specification / Approval |
|---|---|
| EMC Directive | European Community Directive 2014/30/EU; EN 61000-6-2, EN 61000-6-4 |
| Electrical Safety | European Community Directive 2014/35/EU; EN 61010-1 |
| Hazardous Area (cNRTLus) | Class I, Zone 2: AEx/Ex nA nC ic IIC T4 Gc; Class I, Zone 2: AEx/Ex ec nC ic IIC T4 Gc; Class I, Division 2, Groups A, B, C, D (Ta = -20 degC to +65 degC) |
| Hazardous Area (ATEX/IECEx) | Ex nA nC ic IIC T4 Gc; Ex ec nC ic IIC T4 Gc (Ta = -20 degC to +65 degC) |
| Environmental Compliance | RoHS Directive 2011/65/EU; China RoHS EFUP 15 years (SJ/T 11364-2024) |
