The 21000-00-00-15-030-04-02 is a specific configuration of the Bently Nevada 21000 series proximity probe housing assembly, designed for industrial rotating machinery monitoring. This assembly features an aluminum body with a 304 stainless steel sleeve, configured here with Option 00 (Probe not required), Option 15 (1.5 in standoff adapter length), Option 030 (3.0 in probe penetration), and Option 04 (One 3/4-14 NPT plug). This housing is built to comply with API 670 standards for externally mounted proximity probe housings, ensuring consistent, reliable protection for sensor components in heavy-duty environments.
The 21000 series is engineered to provide a robust environmental enclosure for eddy-current probes, protecting them from process fluids and mechanical damage. The inclusion of the 3/4-14 NPT plug (Option 04) facilitates conduit installation while maintaining seal integrity. Users should note that for probe penetration lengths between 1.0 and 2.0 inches, case counter-boring may be required to mitigate side-view effects. When selecting this assembly, the combination of Standoff Adapter (Option C) and Probe Penetration (Option D) dimensions determines the overall effective length and installation fit.
| Orderable Part Number | 21000-00-00-15-030-04-02 | 21000 Series Housing |
| A - Probe with Connector | 00 | Probe not required |
| B - Probe Cable Length | 00 | Probe cable not required |
| C - Standoff Adapter Length | 15 | 1.5 in (38 mm) |
| D - Probe Penetration | 030 | 3.0 in |
| E - Fittings | 04 | One 3/4-14 NPT plug only |
| F - Mounting Thread | 02 | 3/4-14 NPT |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model | 21000 |
| Body Material | Aluminum with 304 stainless steel sleeve |
| Weight | 1.1 kg (2.4 lb) typical |
| Mounting Thread | 3/4-14 NPT |
| Probe Compatibility | 3300 XL 8 mm, 3300 XL 11 mm, 3300 XL NSv |
| Operating Temperature | -51 degC to +177 degC (dependent on probe type) |
| Compliance | RoHS Directive 2011/65/EU |
Ensure that the probe lead is longer than the selected sleeve length. For installations where the probe penetration length (C + D) exceeds 300 mm (12 in), additional sleeve support is required to prevent resonance-induced vibration. Ensure all NPT threads are properly sealed to maintain environmental protection ratings. When utilizing 3/4-14 NPT explosion-proof fittings or plugs, ensure correct torque is applied to maintain the enclosure integrity.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 21000-00-00-15-030-04-02
Country of origin:United States
Product Type: Proximity Probe Housing Assemblies
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 1100g
Dimensions: 8.5cm x 8.5cm x 30.5cm
Shipping port: Xiamen
Warranty: 12 months
The 21000-00-00-15-030-04-02 is a specific configuration of the Bently Nevada 21000 series proximity probe housing assembly, designed for industrial rotating machinery monitoring. This assembly features an aluminum body with a 304 stainless steel sleeve, configured here with Option 00 (Probe not required), Option 15 (1.5 in standoff adapter length), Option 030 (3.0 in probe penetration), and Option 04 (One 3/4-14 NPT plug). This housing is built to comply with API 670 standards for externally mounted proximity probe housings, ensuring consistent, reliable protection for sensor components in heavy-duty environments.
The 21000 series is engineered to provide a robust environmental enclosure for eddy-current probes, protecting them from process fluids and mechanical damage. The inclusion of the 3/4-14 NPT plug (Option 04) facilitates conduit installation while maintaining seal integrity. Users should note that for probe penetration lengths between 1.0 and 2.0 inches, case counter-boring may be required to mitigate side-view effects. When selecting this assembly, the combination of Standoff Adapter (Option C) and Probe Penetration (Option D) dimensions determines the overall effective length and installation fit.
| Orderable Part Number | 21000-00-00-15-030-04-02 | 21000 Series Housing |
| A - Probe with Connector | 00 | Probe not required |
| B - Probe Cable Length | 00 | Probe cable not required |
| C - Standoff Adapter Length | 15 | 1.5 in (38 mm) |
| D - Probe Penetration | 030 | 3.0 in |
| E - Fittings | 04 | One 3/4-14 NPT plug only |
| F - Mounting Thread | 02 | 3/4-14 NPT |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model | 21000 |
| Body Material | Aluminum with 304 stainless steel sleeve |
| Weight | 1.1 kg (2.4 lb) typical |
| Mounting Thread | 3/4-14 NPT |
| Probe Compatibility | 3300 XL 8 mm, 3300 XL 11 mm, 3300 XL NSv |
| Operating Temperature | -51 degC to +177 degC (dependent on probe type) |
| Compliance | RoHS Directive 2011/65/EU |
Ensure that the probe lead is longer than the selected sleeve length. For installations where the probe penetration length (C + D) exceeds 300 mm (12 in), additional sleeve support is required to prevent resonance-induced vibration. Ensure all NPT threads are properly sealed to maintain environmental protection ratings. When utilizing 3/4-14 NPT explosion-proof fittings or plugs, ensure correct torque is applied to maintain the enclosure integrity.
