Bently Nevada

Bently Nevada 21000-16-05-00-019-03-02 21000 Proximity Probe Housing Assembly

SKU 21000-16-05-00-019-03-02

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 21000-16-05-00-019-03-02
  • Origin United States
  • Product Type: Proximity Probe Housing Assemblies
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 1.1 kg
  • Dimensions: 8.5cm x 8.5cm x 30.5cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Proximity Probe Housings

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 21000-16-05-00-019-03-02 21000 Proximity Probe Housing Assembly

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The 21000-16-05-00-019-03-02 is a 21000 Proximity Probe Housing Assembly configuration featuring a 3300 XL 8mm probe (Option 16) and a 0.5 m probe cable (Option 05). This housing assembly is designed for the installation of proximity probe systems, ensuring precise measurement of shaft vibration and axial position in rotating machinery. This specific configuration includes a 1.9 in (Option 019) probe penetration depth, configured without a standoff adapter (Option 00), and is equipped with a cable seal grip fitting (Option 03) and 3/4-14 NPT mounting threads (Option 02). This proximity probe housing is compatible with the 3300 XL transducer system, providing a robust, API 670-compliant environment for eddy-current displacement probes. The housing assembly protects the probe and its connector from the industrial environment, maintaining signal integrity in demanding applications such as power generation, oil and gas, and petrochemical processing.

Features

  • Option 16: 3300 XL 8mm proximity probe
  • Option 05: 0.5 m probe cable length
  • Option 00: No standoff adapter
  • Option 019: 1.9 in probe penetration length
  • Option 03: Cable seal grip fitting (accommodates 1/8 to 3/8 inch cables)
  • Option 02: 3/4-14 NPT mounting thread
  • Aluminum body construction with 304 stainless steel sleeve
  • Compatible with API 670 standard for externally mounted proximity probe housings
  • Operating temperature range: -51 degC to +177 degC

Applications

  • Hydrocarbon and chemical processing plants
  • Steam and gas turbines
  • Centrifugal compressors and pumps
  • Gearboxes and blowers
  • Industrial machinery vibration and axial position monitoring

Ordering Information

Option Code Description
Orderable Part Number 21000-16-05-00-019-03-02 21000 Proximity Probe Housing Assembly
A - Probe with Connector 16 3300 XL 8 mm probe
B - Probe Cable Length 05 0.5 m (20 in)
C - Standoff Adapter 00 No standoff adapter
D - Probe Penetration 019 1.9 in
E - Fittings 03 Cable seal grip
F - Mounting Thread 02 3/4-14 NPT

Technical Specifications

Manufacturer Bently Nevada (Baker Hughes)
Part Number 21000-16-05-00-019-03-02
Body Material Aluminum with 304 stainless steel sleeve
Weight 1.1 kg
Operating Temperature -51 degC to +177 degC
Mounting Thread 3/4-14 NPT
Housing Type Proximity Probe Housing Assembly

Installation Guidelines

Ensure the machine case has adequate clearance for the 1.9 in probe penetration. When using cable seal grips, ensure the cable diameter falls within the 1/8 to 3/8 inch range to maintain a proper seal. If probe penetration length exceeds 300 mm (12 in), additional sleeve support must be installed near the probe to prevent resonance.

Compliance and Certifications

  • RoHS Directive 2011/65/EU
  • API 670 Standard Compliant
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What does the 019 code represent in the probe penetration option?
The 019 code represents a probe penetration length of 1.9 inches.
Is this housing assembly compatible with 3300 XL probes?
Yes, this configuration (Option 16) is specifically designed for the 3300 XL 8mm proximity probe.
What material is the 21000 housing body made of?
The 21000 housing features an aluminum body with a 304 stainless steel sleeve.
What fitting type does the 03 option provide?
Option 03 provides a cable seal grip with grommets for cable sizes ranging from 1/8 inch to 3/8 inch.
