The 21000-16-05-00-084-04-02 is an aluminum Proximity Probe Housing Assembly designed for external mounting of eddy-current proximity probes. This configuration includes a 3300 XL 8 mm probe (Option 16), a 0.5 meter (20 in) probe cable (Option 05), and an 8.4 inch (213 mm) probe penetration length (Option 084). It features a 3/4-14 NPT mounting thread (Option 02) and is configured with a 3/4-14 NPT plug fitting (Option 04) for conduit sealing.
This assembly provides a protective enclosure for probes in industrial machinery environments, ensuring compliance with API 670 standards for externally mounted proximity probe housings. The unit consists of an aluminum housing body, a probe sleeve of the specified penetration length, internal O-rings, and required fittings. It is engineered for applications where secure, robust probe mounting and environmental protection are required for vibration and axial position measurement systems.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 21000-16-05-00-084-04-02 | 21000 Proximity Probe Housing Assembly |
| A - Probe | 16 | 3300 XL 8 mm probe |
| B - Cable Length | 05 | 0.5 m (20 in) |
| C - Standoff Adapter | 00 | No standoff adapter |
| D - Probe Penetration | 084 | 8.4 in (213 mm) |
| E - Fittings | 04 | One 3/4-14 NPT plug |
| F - Mounting Thread | 02 | 3/4-14 NPT |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 21000-16-05-00-084-04-02 |
| Body Material | Aluminum with 304 stainless steel sleeve |
| Weight (Typical) | 1.1 kg (2.4 lb) |
| Operating Temperature | -51 degC to +177 degC (-60 degF to +351 degF) |
| Mounting Thread | 3/4-14 NPT |
| Agency Approvals | CSA Class I, Div 1 & 2, Groups C & D; Class II, Div 1 & 2, Groups E, F, & G |
Ensure that probe sleeve lengths are matched to the specific installation depth requirement. For sleeve lengths exceeding 304 mm (12 inches), install additional sleeve support to mitigate resonance and vibration effects. Verify that the housing and probe are installed in accordance with local hazardous area regulations and Bently Nevada user guides for the 3300 XL transducer system.
