31000-26-05-00-100-03-02: 31000 series English proximity probe housing assembly, configured with a 3300 XL NSv proximity probe, 0.5 m cable length, and 100 mm probe penetration depth. This assembly is designed for the mounting of proximity probes through the machine case, providing external access for gap adjustment or probe replacement without the need for machine disassembly. The unit is constructed from polyphenylene sulfide (PPS), an advanced, high-strength thermoplastic offering corrosion resistance, while internal elements utilize corrosion-resistant stainless steel.
This specific configuration includes Option 03 (two plugs, one M20 fitting, and a cable seal grip for armored probe cables) and Option 02 (3/4-14 NPT mounting thread). It is fully compliant with API 670 standards for externally mounted proximity probe housings and is suitable for radial vibration or Keyphasor measurement when installed in accordance with standard industrial practices.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 31000-26-05-00-100-03-02 | 31000 English Proximity Probe Housing Assembly |
| A - Probe | 26 | 3300 XL NSv probe |
| B - Cable Length | 05 | 0.5 m (20 in) |
| C - Standoff Adapter Length | 00 | No standoff adapter |
| D - Probe Penetration | 100 | 100 mm penetration |
| E - Fittings | 03 | Two plugs, one M20 fitting, one cable seal grip |
| F - Mounting Thread | 02 | 3/4-14 NPT |
| Manufacturer | Bently Nevada |
| Part Number | 31000-26-05-00-100-03-02 |
| Housing Material | Polyphenylene sulfide (PPS) |
| Internal Material | Stainless steel |
| Mounting Thread | 3/4-14 NPT |
| Penetration Depth | 100 mm |
| Probe Type | 3300 XL NSv |
| Compliance | API 670 |
Ensure the machine casing is affixed to the bearing to maintain an accurate relative vibration signal for radial measurements. When installing the housing, secure the outer sleeve into the machine case, insert the probe sleeve, and adjust the gap as required. Disconnect the probe cable prior to fitting the housing over the outer sleeve, then slide the retainer under the retaining nut and tighten. When using hole plugs, tighten the hole plug nuts to 0.5 N-m (5 in-lb) to ensure proper sealing.
Compliant with API 670 standard for externally mounted proximity probe housings. Suitable for hazardous area use when installed with appropriate intrinsically safe (I.S.) barriers and transducer systems.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 31000-26-05-00-100-03-02
Country of origin:United States
Product Type: English Proximity Probe Housing Assemblies
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 1200g
Dimensions: 30.02cm x 12cm x 9.14cm
Shipping port: Xiamen
Warranty: 12 months
