The 330103-00-18-10-12-00 is an 8 mm proximity probe from the Bently Nevada 3300 XL transducer system, featuring an M10 x 1 thread and unarmored construction. This specific configuration includes a 0.0 in unthreaded length (Option 00), 1.8 in case length (Option 18), 1.0 m total system length (Option 10), and is equipped with a FluidLoc cable and standard Miniature ClickLoc connector (Option 12). It meets standard requirements without hazardous area agency approvals (Option 00).
As a core component of the 3300 XL series, this eddy-current proximity probe is designed for critical machinery protection applications, including shaft vibration and axial position measurement. The 3300 XL 8 mm system provides non-contact displacement measurement, ensuring long-term reliability in industrial environments such as power generation and petrochemical facilities. The FluidLoc cable configuration provides enhanced environmental protection for the cable-to-connector interface.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330103-00-18-10-12-00 | 3300 XL 8 mm Proximity Probe, M10 x 1, Unarmored |
| A - Unthreaded Length | 00 | 0.0 in |
| B - Case Length | 18 | 1.8 in |
| C - Total Length | 10 | 1.0 m |
| D - Connector/Cable | 12 | Miniature ClickLoc, FluidLoc cable |
| E - Agency Approval | 00 | Not required |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330103-00-18-10-12-00 |
| Probe Diameter | 8 mm |
| Thread Type | M10 x 1 |
| Armor | None (Unarmored) |
| Cable Type | FluidLoc cable |
| Connector | Miniature ClickLoc |
| Case Length | 1.8 in |
| Unthreaded Length | 0.0 in |
| Total Length | 1.0 m |
| Agency Approvals | Not required |
Ensure the probe is mounted securely using compatible brackets. For M10 x 1 threaded probes, verify that the probe gap is set correctly according to the 3300 XL monitoring system manual. Maintain proper clearance from surrounding metal objects to prevent side-view interference. Route cables away from high-voltage lines and ensure all connections are tight and clean to maintain signal integrity.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-18-10-12-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
