330104-00-13-15-01-00: 3300 XL 8 mm proximity probe, 1/4-28 UNF thread, 0.0 in unthreaded length (Option 00), 1.3 in case length (Option 13), and 1.5 m total length (Option 15). This sensor serves as a primary component in the 3300 XL proximity transducer system, providing non-contact eddy-current displacement measurement for shaft vibration and axial position monitoring applications.
This specific configuration features a standard miniature ClickLoc connector (Option 01) without armor and does not include hazardous area agency approvals (Option 00). It is designed to interface with 3300 XL Proximitor sensors and extension cables, ensuring high-accuracy signal transmission in rotating machinery environments such as turbines, compressors, and pump sets.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330104-00-13-15-01-00 | 3300 XL 8 mm Proximity Probe |
| A - Unthreaded Length | 00 | 0.0 in |
| B - Case Length | 13 | 1.3 in |
| C - Total Length | 15 | 1.5 m |
| D - Connector/Cable | 01 | Miniature ClickLoc, standard |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330104-00-13-15-01-00 |
| Probe Diameter | 8 mm |
| Thread Size | 1/4-28 UNF |
| Total Length | 1.5 m |
| Connector Type | Miniature ClickLoc |
| Operating Temperature | -51 degC to +177 degC |
| Tip Material | Polyphenylene sulfide (PPS) |
| Linear Range | 2 mm |
| Agency Approval | None required |
Install the probe using the provided mounting threads to ensure proper clearance and gap distance from the target surface. Avoid overtightening the probe tip against the shaft during installation. Ensure the extension cable is routed away from high-voltage AC lines to prevent signal interference. Use proper grounding techniques for the 3300 XL monitoring system to maintain signal integrity.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330104-00-13-15-01-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
