The 31000-30-05-40-014-03-02 is a specialized 31000 series proximity probe housing assembly, configured for the integration of a 3300 XL NSv proximity probe with a connector protector (Option 30). This assembly features a 0.5 m probe cable length (Option 05), a 40 mm standoff adapter length (Option 40), and specific probe penetration settings (Option 014). It includes two plugs, one M20 fitting, and one cable seal grip for armored probe cables (Option 03), mounted via a 3/4-14 NPT thread (Option 02).
Engineered for use in rotating machinery, the 31000 series housing allows for external access to the proximity probe and its extension cable. This design facilitates efficient gap adjustment and probe replacement without requiring the disassembly of the machine case. Constructed from high-strength, corrosion-resistant polyphenylene sulfide (PPS) with stainless steel components, this assembly provides mechanical and environmental protection compliant with API 670 standards.
The 31000 series housing is used for mounting proximity probes through machine cases in heavy industrial environments, including:
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 31000-30-05-40-014-03-02 | 31000 Proximity Probe Housing Assembly |
| A - Probe with Connector | 30 | 3300 XL NSv probe with connector protector |
| B - Probe Cable Length | 05 | 0.5 m (20 in) |
| C - Standoff Adapter Length | 40 | 40 mm minimum length |
| D - Probe Penetration | 014 | Probe penetration option |
| E - Fittings | 03 | Two plugs, one M20 fitting, one cable seal grip |
| F - Mounting Thread | 02 | 3/4-14 NPT |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 31000-30-05-40-014-03-02 |
| Housing Material | Polyphenylene sulfide (PPS) |
| Internal Components | Stainless steel |
| Mounting Thread | 3/4-14 NPT |
| Fittings | One M20 fitting, two plugs, one cable seal grip |
| Standard Compliance | API 670 |
| Weight | 1.2 kg |
Install the outer sleeve directly into the machine case before fitting the housing. When measuring radial vibration, ensure the machine casing is affixed to the bearing to maintain an accurate relative vibration signal. Tighten hole plug nuts to 0.5 N-m (5 in-lbs) if unused holes are present. For probe penetration lengths between 25 and 50 mm, counter-boring the machine case may be necessary to minimize side-view or rear-view effects.
Compliant with API 670 Standard. Suitable for use in intrinsically safe hazardous area applications when installed with compatible transducer systems and appropriate I.S. barriers.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 31000-30-05-40-014-03-02
Country of origin:United States
Product Type: English Proximity Probe Housing Assemblies
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 1200g
Dimensions: 30.02cm x 12cm x 9.14cm
Shipping port: Xiamen
Warranty: 12 months
