The Bently Nevada 330101-00-28-10-02-00 is an unarmored 8 mm proximity probe configured with a fully threaded 3/8-24 UNF housing (0.0 inches unthreaded length), a 2.8-inch case length, and a 1.0-meter (3.3 feet) standard coaxial cable with a miniature ClickLoc connector. Designed for systems that do not require hazardous area approvals, this specific variant provides non-contact vibration and shaft position measurements in industrial machinery. It acts as a critical sensing element within a 3300 XL monitoring chain, pairing seamlessly with a 330180 series Proximitor sensor and a corresponding standard extension cable to deliver highly accurate displacement readings.
This proximity probe utilizes eddy-current technology to track dynamic displacement, such as radial shaft vibration and axial thrust position. Since it is constructed without protective armor, this variant is ideal for installations where the cable path is adequately protected inside conduits or dry machine casings. Its 1.0-meter cable must be integrated into a 5-meter or 9-meter overall system configuration to maintain precise calibration and minimize interference.
Typical applications for this probe include turbine shaft vibration and position monitoring, critical compressor and pump rotor displacement measurements, and general rotating machinery protection within power generation, oil and gas, and chemical processing facilities.
| Option Segment | Code | Description |
|---|---|---|
| Orderable Part Number | 330101-00-28-10-02-00 | 3300 XL 8 mm Proximity Probe, 3/8-24 UNF thread, without armor |
| A - Unthreaded Length Option | 00 | 0.0 in (0 mm) unthreaded length |
| B - Overall Case Length Option | 28 | 2.8 in (71 mm) case length |
| C - Total Length Option | 10 | 1.0 meter (3.3 feet) total length |
| D - Connector and Cable-Type Option | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval Option | 00 | Not required |
| Manufacturer | Bently Nevada |
| Part Number/Model | 330101-00-28-10-02-00 |
| Product Family | 3300 XL 8 mm Proximity Transducer System |
| Probe Diameter | 8 mm |
| Operating Principle | Eddy current |
| Measurement Type | Displacement (proximity) |
| Linear Range | 2.0 mm (80 mils), starting at 0.25 mm (10 mils) from target |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) nominal |
| Probe DC Resistance | 7.59 ohms +/- 0.50 ohms (from center conductor to outer conductor) |
| Operating Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Dimensions | 45 mm x 95 mm x 95 mm (H x W x D) |
| Weight | 0.14 kg |
To ensure proper operation of the proximity probe, verify that it is mounted with the correct probe gap (typically adjusted to -9 Vdc or approximately 1.27 mm / 50 mils) according to system calibration. Route the probe cable with proper shielding and grounding practices to eliminate noise coupling. Ensure that the thread engagement limits are respected during installation, and finger-tighten the ClickLoc connectors to prevent damage to the gold-plated contacts.
