The 330102-00-28-05-02-00 is an armored 3300 XL 8 mm Proximity Probe configured for non-contact eddy-current displacement measurements in critical machinery. This specific variant features a 0.0 in unthreaded length (Option 00), 2.8 in case length (Option 28), and a 0.5 m total probe length (Option 05) with a standard miniature coaxial ClickLoc connector (Option 02). The armored design provides mechanical protection for the probe cable, making it suitable for industrial environments where abrasion or physical hazards are a concern.
This probe is a primary component of the 3300 XL 8 mm transducer system, designed to work in conjunction with the 3300 XL Proximitor sensor and 3300 XL extension cable. It delivers precise shaft vibration and axial position data, critical for monitoring rotating machinery such as turbines, compressors, and pumps.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330102-00-28-05-02-00 | 3300 XL 8 mm Proximity Probe, Armored |
| A - Unthreaded Length | 00 | 0.0 in |
| B - Case Length | 28 | 2.8 in |
| C - Total Length | 05 | 0.5 m |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc, standard cable |
| E - Agency Approval | 00 | Not required |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330102-00-28-05-02-00 |
| Probe Diameter | 8 mm |
| Thread Size | 3/8-24 UNF |
| Armor | Yes |
| Cable Type | Standard |
| Connector Type | Miniature coaxial ClickLoc |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel |
| Max Connector Torque | 0.565 Nm (5 in-lbf) |
| Probe Case Torque | 11.2 Nm (100 in-lbf) |
Ensure the probe is gapped correctly according to the system manual for the specific machinery application. Use the appropriate mounting bracket (standard or threaded) to secure the probe. When routing the armored cable, observe the minimum bend radius of 25.4 mm (1.0 in) to prevent damage. Connectors should be tightened finger-tight; do not use excessive torque. Verify that the combined length of the probe and extension cable matches the calibrated length for the connected Proximitor sensor.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330102-00-28-05-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Sonda di prossimità
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
