The 330905-00-12-05-02-00 is a 3300 XL NSv proximity probe configured for applications requiring an M10x1 thread and non-armored construction. This transducer system is specifically engineered for machinery where space is limited or target surface area is restricted, such as aeroderivative turbines and small-bore rotating equipment. This configuration features a 0.5-meter cable length and a standard miniature coaxial ClickLoc connector, designed for seamless integration with the 3300 XL NSv Proximitor Sensor and extension cable.
The 3300 XL NSv proximity transducer system provides reliable non-contact displacement measurement for radial vibration and axial position monitoring. By optimizing the probe tip and coil design, the NSv system maintains a consistent scale factor even when monitoring targets smaller than the traditional 20 mm (0.8 in) diameter, making it the industry standard for high-speed, small-shaft machinery protection.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330905-00-12-05-02-00 | 3300 XL NSv Proximity Probe, M10x1 thread, Non-Armored |
| A - Unthreaded Length | 00 | 0.0 in (0 mm) |
| B - Case Length | 12 | 1.2 in |
| C - Total Length | 05 | 0.5 meter (20 in) |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330905-00-12-05-02-00 |
| Probe Thread | M10 x 1 |
| Probe Type | Standard Mount, Non-Armored |
| Cable Type | 75 Ohm coaxial, FEP insulated |
| System Length | 0.5 m probe |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 304 stainless steel |
| Connector | Miniature coaxial ClickLoc |
Ensure the probe is mounted securely using the provided M10x1 threads. When routing the cable, avoid sharp bends that may damage the FEP insulation. For systems requiring environmental protection, use a connector protector on the probe-to-extension cable junction. The proximity system should be checked for proper gap settings during installation to ensure it operates within the linear range of the transducer.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330905-00-12-05-02-00
Country of origin:United States
Product Type: Sonde di prossimità 3300 NSv
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 120g
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
The 330905-00-12-05-02-00 is a 3300 XL NSv proximity probe configured for applications requiring an M10x1 thread and non-armored construction. This transducer system is specifically engineered for machinery where space is limited or target surface area is restricted, such as aeroderivative turbines and small-bore rotating equipment. This configuration features a 0.5-meter cable length and a standard miniature coaxial ClickLoc connector, designed for seamless integration with the 3300 XL NSv Proximitor Sensor and extension cable.
The 3300 XL NSv proximity transducer system provides reliable non-contact displacement measurement for radial vibration and axial position monitoring. By optimizing the probe tip and coil design, the NSv system maintains a consistent scale factor even when monitoring targets smaller than the traditional 20 mm (0.8 in) diameter, making it the industry standard for high-speed, small-shaft machinery protection.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330905-00-12-05-02-00 | 3300 XL NSv Proximity Probe, M10x1 thread, Non-Armored |
| A - Unthreaded Length | 00 | 0.0 in (0 mm) |
| B - Case Length | 12 | 1.2 in |
| C - Total Length | 05 | 0.5 meter (20 in) |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330905-00-12-05-02-00 |
| Probe Thread | M10 x 1 |
| Probe Type | Standard Mount, Non-Armored |
| Cable Type | 75 Ohm coaxial, FEP insulated |
| System Length | 0.5 m probe |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 304 stainless steel |
| Connector | Miniature coaxial ClickLoc |
Ensure the probe is mounted securely using the provided M10x1 threads. When routing the cable, avoid sharp bends that may damage the FEP insulation. For systems requiring environmental protection, use a connector protector on the probe-to-extension cable junction. The proximity system should be checked for proper gap settings during installation to ensure it operates within the linear range of the transducer.
Global Express Shipping
Returns & Warranty
Orders are processed and delivered Monday-Friday (excluding public holidays).
For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .
| Country of origin |
United States
|
