Bently Nevada

Bently Nevada 330102-04-45-50-01-00 3300 XL 8 mm Sonda di prossimità

SKU 330102-04-45-50-01-00

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330102-04-45-50-01-00
  • Origin United States
  • Product Type: 3300 XL 8 mm Sonda di prossimità
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.6 kg
  • Dimensions: 9.5 mm x 9.5 mm x 114.3 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330102-04-45-50-01-00 3300 XL 8 mm Sonda di prossimità

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

Steel probe case with 3/8-24 UNF threads featuring a 0.4 in unthreaded length (Option 04) and a 4.5 in overall case length (Option 45) — 330102-04-45-50-01-00 proximity probe.

Equipped with stainless steel armor for robust mechanical protection, this configuration includes a miniature coaxial ClickLoc connector with an integrated connector protector (Option 01). The 5.0-meter total length (Option 50) means the probe connects directly to a 5-meter 3300 XL Proximitor sensor, eliminating the need for a separate extension cable. Operating as an eddy-current system, it provides continuous shaft vibration, axial position, and speed measurements on rotating machinery.

Features

  • 3/8-24 UNF threaded steel probe case with robust stainless steel armor.
  • 0.4 in unthreaded length (Option 04) for precise clearance adjustment.
  • 4.5 in overall case length (Option 45).
  • 5.0 m total length (Option 50) designed to connect directly to a matching 5-meter Proximitor sensor.
  • ClickLoc coaxial connector featuring a fluorosilicone connector protector (Option 01) to seal out moisture.
  • Unapproved variant (Option 00) for standard non-hazardous industrial environments.

Applications

  • Steam and gas turbine shaft vibration and position monitoring.
  • Hydroelectric turbine shaft displacement tracking.
  • Boiler feed pump axial position thrust measurements.
  • Large industrial compressor and blower vibration protection.
  • Gearbox shaft dynamic motion monitoring.

Ordering Information

Option / Segment Code on This SKU Description
Orderable Part Number 330102-04-45-50-01-00 3300 XL 8 mm Proximity Probe, 3/8-24 UNF thread, with armor
A - Unthreaded Length Option 04 0.4 in unthreaded length
B - Case Length Option 45 4.5 in overall case length
C - Total Length Option 50 5.0 meters (16.4 feet) total length
D - Connector and Cable-Type Option 01 Miniature coaxial ClickLoc connector with connector protector, standard cable
E - Agency Approval Option 00 Agency approval not required

Technical Specifications

Parameter Specification
Manufacturer Bently Nevada (Baker Hughes)
Model / Part Number 330102-04-45-50-01-00
Transducer Type Non-contact eddy-current proximity probe
Probe Tip Diameter 8.0 mm (0.31 in)
Case Thread Size 3/8-24 UNF-2A
Unthreaded Length 0.4 in (10.2 mm)
Overall Case Length 4.5 in (114.3 mm)
Total Cable Length 5.0 meters (16.4 feet)
Cable Type Standard cable with stainless steel armor and FEP outer jacket
Connector Type Miniature coaxial ClickLoc
Connector Protector Included (Fluorosilicone material)
Agency Approval None (Option 00)
Operating Temperature -52 degC to +177 degC
Differential Pressure Seal Up to 70 psi (4.8 bar) across probe tip
Probe Case Material 303 Stainless Steel
Probe Tip Material Polyphenylene sulfide (PPS)
Minimum Cable Bend Radius 25.4 mm (1.0 in)
Weight 0.60 kg
Dimensions 9.5 mm x 9.5 mm x 114.3 mm (H x W x D)

Connections and Interfaces

Connector Component Connection Type / Details
Probe Connector Miniature male coaxial ClickLoc connector with gold-plated brass body
Extension Interface Connects directly to female ClickLoc connector of a 5-meter Proximitor Sensor

Installation Guidelines

  • Secure the probe housing using a 9/16 inch lock nut (supplied).
  • Verify that the unthreaded length is at least 0.8 in less than the overall case length to maintain physical housing stability.
  • Maintain a minimum cable bend radius of 25.4 mm (1.0 in) to prevent damaging the internal coaxial core and outer armor.
  • Hand-tighten ClickLoc connectors to click feedback. Do not use tools on the gold-plated connectors.
  • Run probe cables through dedicated, grounded conduits to avoid electromagnetic interference.

Compliance and Certifications

  • CE Compliant
  • RoHS Compliant
  • Manufactured under ISO 9001 certified quality standards
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
Quali sono la lunghezza e i parametri dell’alloggiamento specifici di questa variante della sonda 330102?
Questa configurazione specifica (330102-04-45-50-01-00) presenta un corpo in acciaio con filettatura 3/8-24 UNF, una lunghezza non filettata di 0,4 pollici (opzione 04), una lunghezza complessiva dell’involucro di 4,5 pollici (opzione 45) e una lunghezza complessiva del cavo di 5,0 metri (opzione 50).
Perché questa sonda richiede direttamente un sensore Proximitor da 5 metri?
Con una lunghezza complessiva del cavo di 5,0 metri (opzione 50), la sonda è compatibile con la regolazione della lunghezza elettrica del sistema quando viene collegata direttamente a un sensore Proximitor da 5 metri, eliminando la necessità di un cavo di prolunga separato.
Qual è la funzione del tipo di connettore dell’opzione 01?
L’opzione 01 indica un connettore coassiale ClickLoc miniaturizzato, completo di una protezione integrata del connettore in fluorosilicone, che sigilla il punto di connessione contro l’umidità e i contaminanti industriali.
La sonda 330102-04-45-50-01-00 dispone di certificazioni per aree pericolose?
No, questa sonda specifica è ordinata con l’opzione 00 per le approvazioni degli enti, il che significa che è destinata all’uso in ambienti industriali standard e non pericolosi, dove non sono richieste certificazioni.
