Non-contact eddy-current displacement probe for 3300 XL monitoring chains; orderable configuration 330103-00-04-10-01-05 (0.0 in unthreaded length, 0.4 in case length, 1.0 m total length). This transducer is used in 3300 XL 8 mm proximity transducer systems to measure shaft vibration and axial position on critical rotating machinery. The 330103 model provides an unarmored construction, suitable for environments where mechanical abrasion is not the primary concern.
Configuration 330103-00-04-10-01-05 utilizes the miniature coaxial ClickLoc connector (Option 01) equipped with a connector protector to ensure signal integrity during installation. It is certified for hazardous locations under the CSA, ATEX, and IECEx approval standards (Option 05).
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-00-04-10-01-05 | 3300 XL 8 mm Proximity Probe, 3/8-24 UNF, Unarmored |
| A - Unthreaded Length | 00 | 0.0 in |
| B - Case Length | 04 | 0.4 in |
| C - Total Length | 10 | 1.0 m |
| D - Connector/Cable | 01 | Miniature ClickLoc, includes connector protector |
| E - Agency Approval | 05 | CSA, ATEX, IECEx |
| Manufacturer | Bently Nevada |
| Part Number | 330103-00-04-10-01-05 |
| Probe Diameter | 8 mm |
| Thread Size | 3/8-24 UNF |
| Total Length | 1.0 m |
| Connector Type | Miniature coaxial ClickLoc |
| Armor | None |
| Agency Approvals | CSA, ATEX, IECEx |
Ensure the probe is mounted securely in a mounting bracket or machine housing to minimize mechanical resonance. Verify that the probe tip maintains the correct gap distance relative to the target shaft, as specified in the system documentation. Route the coaxial extension cable away from high-voltage AC lines to prevent electromagnetic interference. Use the provided connector protector during installation to prevent contamination of the ClickLoc interface.
This product meets international standards for hazardous area operation including CSA, ATEX, and IECEx certifications as specified by Option 05.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-04-10-01-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
