Description

The 330103-00-05-10-02-00 is a 3300 XL 8 mm proximity probe featuring an M10 x 1 thread and unarmored construction. Designed for non-contact displacement measurement, this probe is a critical component of the 3300 XL 8 mm transducer system used for monitoring shaft vibration and axial position on rotating machinery. The configuration specifies 0.0 in unthreaded length (Option 00), 0.5 in case length (Option 05), 1.0 m total system length (Option 10), and a Miniature ClickLoc coaxial connector (Option 02).

This probe is compatible with the 3300 XL Proximitor sensor and 3300 XL extension cable. The M10 x 1 thread configuration provides specific mounting compatibility for machinery designed for metric interfaces, while the unarmored cable construction is suitable for installations where additional mechanical abrasion protection is not required. It functions as a complete measuring chain when connected to the appropriate 3300 XL Proximitor sensor, providing linear voltage output proportional to the distance between the probe tip and the observed conductive surface.

Features

• Model 330103: 8 mm proximity probe with M10 x 1 threads, unarmored.
• Option 00 (Unthreaded Length): 0.0 in unthreaded length configuration.
• Option 05 (Case Length): 0.5 in overall case length.
• Option 10 (Total Length): 1.0 m system length.
• Option 02 (Connector/Cable): Miniature ClickLoc coaxial connector with standard cable.
• Option 00 (Agency Approval): Not required.
• System Compatibility: Designed for use with 3300 XL Proximitor sensors and 3300 XL extension cables.
• Measurement Capability: High-precision non-contact eddy-current displacement for shaft vibration and position monitoring.

Applications

• Critical rotating machinery protection
• Turbine and compressor shaft vibration monitoring
• Axial position (thrust) measurement
• Radial vibration analysis
• Industrial bearing and journal monitoring

Ordering Information

Technical Specifications

Installation Guidelines

Ensure that the total system length (probe length + extension cable length) matches the requirements of the 3300 XL Proximitor sensor used in the measurement chain. Probes should be installed with the appropriate mounting bracket to ensure electrical isolation if required by the application. Maintain recommended probe gaps for optimal linear range and avoid sharp bends in the coaxial cable to prevent damage to the cable shielding. Connectors should be hand-tightened and secured to prevent vibration-induced loosening; use of the Bently Nevada connector protector kit is recommended for environmental sealing.
