The 330103-00-08-10-02-05 is a 3300 XL 8 mm proximity probe featuring an M10x1 thread and non-armored construction, designed for non-contact eddy-current displacement measurement in 3300 XL monitoring chains. This configuration includes 0.0 in unthreaded length (Option 00), 80 mm case length (Option 08), 1.0 m total length (Option 10), and the standard Miniature ClickLoc connector (Option 02).
This probe is intended for use in critical rotating machinery applications, such as steam turbines, compressors, and pumps, to provide essential shaft vibration and axial position data. The 330103 series is engineered for durability and reliability in demanding industrial environments, with this specific unit rated for hazardous area operations through its CSA, ATEX, and IECEx approvals (Option 05).
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330103-00-08-10-02-05 | 3300 XL 8 mm Proximity Probe, M10x1 |
| A - Unthreaded Length | 00 | 0.0 in |
| B - Case Length | 08 | 80 mm |
| C - Total Length | 10 | 1.0 m |
| D - Connector | 02 | Miniature ClickLoc, standard cable |
| E - Agency Approval | 05 | CSA, ATEX, IECEx |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Probe Diameter | 8 mm |
| Thread Size | M10 x 1 |
| Material | Non-armored |
| Connector Type | Miniature ClickLoc |
| Total Length | 1.0 m |
| Case Length | 80 mm |
| Approvals | CSA, ATEX, IECEx |
Ensure the probe is gapped correctly to prevent contact with the observed shaft. Use the appropriate mounting bracket (standard or phenolic for electrical isolation) and secure using the provided locknuts. Verify cable routing is protected from high-heat areas and mechanical stress. Ensure total system length—including probe, extension cable, and Proximitor sensor—matches the calibrated monitoring channel.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-08-10-02-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
