330103-00-15-05-01-00 is a 3300 XL 8 mm proximity probe configuration featuring 0.0 in unthreaded length (Option 00), 1.5 in case length (Option 15), 0.5 m total length (Option 05), and a Miniature ClickLoc connector with connector protector (Option 01). This eddy-current transducer system is designed to provide precise, non-contact measurement of shaft vibration and axial position on critical rotating machinery.
This 330103 model utilizes M10 x 1 threading and an unarmored cable construction. It is engineered to operate within the 3300 XL 8 mm transducer chain, compatible with 3300 XL Proximitor sensors and extension cables. The inclusion of the connector protector (Option 01) enhances the environmental integrity of the connection point. This configuration carries no specialized agency approval (Option 00).
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330103-00-15-05-01-00 | 3300 XL 8 mm Proximity Probe |
| A - Unthreaded Length | 00 | 0.0 in unthreaded length |
| B - Case Length | 15 | 1.5 in case length |
| C - Total Length | 05 | 0.5 meter |
| D - Connector/Cable | 01 | Miniature ClickLoc, with connector protector, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada |
| Model / Part Number | 330103-00-15-05-01-00 |
| Probe Diameter | 8 mm |
| Thread Type | M10 x 1 |
| Unthreaded Length | 0.0 in |
| Case Length | 1.5 in |
| Total System Length | 0.5 m |
| Connector Type | Miniature coaxial ClickLoc |
| Cable Type | Standard (unarmored) |
| Connector Protector | Included |
| Agency Approvals | Not required |
Proper installation of the 330103 probe requires adherence to Bently Nevada standard practices for gap calibration and cable routing. Ensure the probe is mounted in a stable, vibration-resistant bracket. When using the included connector protector, ensure the threads are clean and free of debris to maintain an environmental seal. Avoid routing signal cables alongside high-voltage power lines to prevent electromagnetic interference.
This specific SKU (Option 00) is designated as "Not required" for agency approval. Users requiring hazardous area certifications (CSA, ATEX, IECEx) must select Option 05 configurations.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-15-05-01-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
