330103-00-25-50-02-02 is a 3300 XL 8 mm proximity probe configuration featuring an M10 x 1 thread, 0.0 in unthreaded length (Option 00), 2.5 in case length (Option 25), and 5.0 m total length (Option 50). This probe is designed for non-contact eddy-current displacement measurement in 3300 XL transducer systems, providing precise shaft vibration and axial position data for critical rotating machinery.
This configuration utilizes a miniature coaxial ClickLoc connector with standard cable construction (Option 02). The 3300 XL 8 mm system is fully compliant with API 670 standards, providing high-accuracy monitoring in environments ranging from general industrial processes to complex turbomachinery protection.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-00-25-50-02-02 | 3300 XL 8 mm Proximity Probe |
| A - Unthreaded Length | 00 | 0.0 in unthreaded length |
| B - Overall Case Length | 25 | 2.5 in case length |
| C - Total Length | 50 | 5.0 m total length |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 02 | Refer to product documentation for specific regional approval |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330103-00-25-50-02-02 |
| Probe Type | 3300 XL 8 mm Proximity Probe |
| Thread Size | M10 x 1 |
| Probe Diameter | 8 mm |
| Total System Length | 5.0 m |
| Connector Type | Miniature coaxial ClickLoc |
| Body Material | AISI 303 or 304 Stainless Steel |
| Operating Temperature | -51 degC to +177 degC |
Ensure the probe is installed with the correct gap distance as specified by the machinery manufacturer or the 3300 XL system documentation. Use the appropriate mounting bracket (e.g., M10 x 1 threaded bracket) and lock nut to secure the probe position. Protect connectors from environmental contamination using connector protectors. Grounding and shielding practices must be followed to ensure signal integrity within the proximity monitoring chain.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-25-50-02-02
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
