330103-05-13-10-02-00: 3300 XL 8 mm proximity probe configuration featuring 0.5 in unthreaded length (Option 05), 1.3 in case length (Option 13), and 1.0 m total length (Option 10). This non-contact eddy-current transducer is designed for use in 3300 XL 8 mm monitoring chains to measure shaft vibration and axial position on critical rotating machinery.
This probe utilizes a standard miniature coaxial ClickLoc connector (Option 02) and requires no agency approval (Option 00). It is constructed with an M10 x 1 thread without internal armor. The system is engineered for reliable operation in demanding industrial environments, providing accurate gap measurements when paired with a compatible 3300 XL Proximitor sensor and extension cable.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-05-13-10-02-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 thread |
| A - Unthreaded Length | 05 | 0.5 in |
| B - Case Length | 13 | 1.3 in |
| C - Total Length | 10 | 1.0 m |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330103-05-13-10-02-00 |
| Probe Diameter | 8 mm |
| Thread Size | M10 x 1 |
| Total Length | 1.0 m |
| Connector Type | Miniature coaxial ClickLoc |
| Armor | None |
| Agency Approvals | Not required |
Ensure proper probe gapping according to the 3300 XL monitoring system manual to maintain linearity and measurement accuracy. Verify that the combined length of the probe and extension cable matches the total system length requirement of the Proximitor sensor. Use standard shielding and grounding practices for signal cabling to minimize electrical interference in the installation environment.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-05-13-10-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
