The 330103-07-16-05-02-00 is a 3300 XL 8 mm proximity probe featuring an M10 x 1 thread and an unarmored construction. This specific configuration includes an unthreaded length of 0.7 inches (Option 07) and an overall case length of 1.6 inches (Option 16). Designed for non-contact eddy-current displacement measurement, this probe is a critical component in 3300 XL monitoring chains, providing precise shaft vibration and axial position data for rotating machinery such as turbines, compressors, and pumps.
This unit is supplied with a 0.5-meter total system length (Option 05) and is terminated with a standard miniature coaxial ClickLoc connector (Option 02) without a connector protector. As an Option 00 configuration, it does not include additional hazardous area agency approvals. The 330103 probe is engineered for reliability in demanding industrial environments, ensuring consistent signal integrity when paired with 3300 XL extension cables and Proximitor sensors.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-07-16-05-02-00 | 3300 XL 8 mm Proximity Probe, M10 x 1, Unarmored |
| A - Unthreaded Length | 07 | 0.7 in (17.8 mm) |
| B - Case Length | 16 | 1.6 in (40.6 mm) |
| C - Total Length | 05 | 0.5 meter (1.6 feet) |
| D - Connector/Cable | 02 | Miniature ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model | 330103-07-16-05-02-00 |
| System Type | 3300 XL 8 mm Proximity Transducer System |
| Probe Thread | M10 x 1 |
| Armor | None |
| Connector Type | Miniature coaxial ClickLoc |
| Cable Type | Standard |
| Total Length | 0.5 meter |
| Agency Approvals | Not required |
Ensure the probe is installed with the correct gap distance as specified in the 3300 XL 8 mm Transducer System manual to maintain linear output. When routing the coaxial cable, avoid sharp bends and maintain separation from high-voltage AC cabling to prevent EMI interference. Verify that the probe mounting bracket is secure and that the probe body is not subjected to excessive vibration or stress during operation.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-07-16-05-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
