330103-08-15-10-02-00 is an 8 mm proximity probe configuration within the 3300 XL transducer system, featuring a 1/4-28 UNF thread, 0.8 in unthreaded length (Option 08), 1.5 in case length (Option 15), and a 1.0 m total length (Option 10). This probe is equipped with a miniature ClickLoc connector and standard cable (Option 02) and is supplied without hazardous area agency approvals (Option 00).
The 330103 series probe provides non-contact eddy-current displacement measurement for critical machinery monitoring, serving as a primary component in 3300 XL 8 mm monitoring chains. It is designed for use with the 330180 Proximitor sensor and 330130 extension cable to monitor shaft vibration and axial position on turbines, compressors, and other rotating equipment. The system maintains high accuracy and linearity by compensating for cable length and probe impedance variations.
| Option | Code on This SKU | Description |
| Orderable Part Number | 330103-08-15-10-02-00 | 3300 XL 8 mm Proximity Probe, 1/4-28 UNF |
| A - Unthreaded Length | 08 | 0.8 in |
| B - Case Length | 15 | 1.5 in |
| C - Total Length | 10 | 1.0 m |
| D - Connector/Cable | 02 | Miniature ClickLoc, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada |
| Part Number | 330103-08-15-10-02-00 |
| Probe Diameter | 8 mm |
| Thread Size | 1/4-28 UNF |
| System Length | 1.0 m |
| Connector Type | Miniature ClickLoc |
| Linear Range | 2 mm (80 mils) |
| Operating Temperature | -51 degC to +177 degC |
| Case Material | AISI 303 or 304 stainless steel |
Ensure that probe spacing is set according to the transducer system gap requirements to maintain linear output. Use caution when installing in threaded holes to prevent overtightening the probe body. Cables should be routed away from high-voltage power lines and secured to prevent vibration-induced wear. Connections must be made to the 330180 Proximitor sensor using the standard ClickLoc interface, ensuring the connector is clean and dry before mating.
This configuration (Option 00) does not carry specific hazardous area approvals. Users must verify local installation codes if required by facility safety standards.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-08-15-10-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
