The 330103-10-20-10-02-00 is a 3300 XL 8 mm proximity probe featuring an M10 x 1 thread and a non-armored design. This configuration specifies 100 mm of unthreaded length (Option 10) and a 200 mm total case length (Option 20), paired with a 1.0 meter total system length (Option 10). The probe utilizes a standard miniature coaxial ClickLoc connector (Option 02) without hazardous area approvals (Option 00).
As a core component of the 3300 XL 8 mm transducer system, this probe is designed for precise, non-contact eddy-current displacement measurement. It is intended for use with a matching 3300 XL Proximitor sensor and extension cable to provide continuous shaft vibration and axial position monitoring in critical rotating machinery, such as gas turbines, steam turbines, and centrifugal compressors. The M10 x 1 threading provides compatibility with specific metric mounting configurations commonly found in international industrial standards.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330103-10-20-10-02-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 |
| A - Unthreaded Length | 10 | 100 mm |
| B - Case Length | 20 | 200 mm |
| C - Total Length | 10 | 1.0 meter |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330103-10-20-10-02-00 |
| System Type | 3300 XL 8 mm Proximity Transducer System |
| Probe Diameter | 8 mm |
| Thread Size | M10 x 1 |
| Armor | None (Non-armored) |
| Connector Type | Miniature coaxial ClickLoc |
| Cable Type | Standard |
| Operating Temperature | -51 degC to +177 degC |
| Linear Range | 2 mm (80 mil) |
| Target Material | AISI 4140 steel (standard calibration) |
Ensure the probe is mounted securely using compatible M10 x 1 threaded hardware. Verify the probe gap during installation to maintain the specified linear range for the transducer system. Route extension cables away from high-voltage lines or sources of electrical noise to prevent signal interference. Use caution when tightening the probe to avoid damaging the M10 threads. Always ensure the connector is clean and free of moisture or debris before mating with the extension cable.
