Description

The 330104-00-04-05-02-00 is a 3300 XL 8 mm proximity probe featuring an M10 x 1 thread, protective armor, and a 0.5 meter system length. This configuration includes a 0 mm unthreaded length (Option 00), a 40 mm case length (Option 04), and a standard ClickLoc connector (Option 02) without agency approvals (Option 00). It is designed for use within 3300 XL monitoring chains for non-contact eddy-current displacement measurement.

The 3300 XL 8 mm transducer system provides consistent and reliable gap-to-voltage performance for critical machinery monitoring, such as shaft vibration and axial position measurements on turbines, compressors, and large rotating equipment. This variant, with its armored cable, provides increased mechanical protection in challenging industrial environments, while the M10 x 1 thread configuration ensures compatibility with specific metric mounting requirements.

Features

• M10 x 1 threaded probe body with protective armor
• 0 mm unthreaded length and 40 mm case length
• 0.5 meter total system length for compact installations
• Miniature coaxial ClickLoc connector (standard cable, no connector protector)
• Non-contact eddy-current sensing technology
• Compatible with 3300 XL Proximitor sensors and extension cables

Applications

• Turbine and compressor shaft vibration monitoring
• Rotor axial position measurement
• Critical rotating machinery protection
• Fluid film bearing health assessment
• Industrial environments requiring armored mechanical protection

Ordering Information

Technical Specifications

Installation Guidelines

• Ensure the probe is gapped according to the 3300 XL system manual for the specific machinery application.
• The armor provides mechanical protection; route cables carefully to avoid sharp bends that exceed the minimum bend radius.
• Use the appropriate mounting bracket (e.g., M10 x 1 threaded bracket) to secure the probe body.
• Protect all connectors from moisture and contaminants using approved connector protectors or self-fusing silicone tape.
