330104-00-08-05-01-05 is a 3300 XL 8 mm proximity probe configuration featuring an M10 x 1 threaded case, an armored cable, 0.0 mm unthreaded length (Option 00), 80 mm case length (Option 08), and a 0.5 meter total system length (Option 05). This unit is equipped with a miniature coaxial ClickLoc connector including a connector protector and standard cable (Option 01), and it holds CSA, ATEX, and IECEx hazardous area approvals (Option 05).
As part of the 3300 XL 8 mm Proximity Transducer System, this probe provides accurate, non-contact eddy-current displacement measurement for critical rotating machinery. The 330104 series is designed with integral armor to protect the cable in harsh industrial environments. It is fully compatible with 3300 XL Proximitor sensors and extension cables to form a complete monitoring chain for shaft vibration, axial position, and rotor speed measurements in power generation, oil and gas, and petrochemical applications.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330104-00-08-05-01-05 | 3300 XL 8 mm Proximity Probe, M10 x 1, Armored |
| A - Unthreaded Length | 00 | 0.0 mm |
| B - Case Length | 08 | 80 mm |
| C - Total Length | 05 | 0.5 meter (1.6 feet) |
| D - Connector/Cable | 01 | ClickLoc connector with connector protector, standard cable |
| E - Agency Approval | 05 | CSA, ATEX, IECEx Approvals |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330104-00-08-05-01-05 |
| Probe Type | 3300 XL 8 mm Proximity Probe |
| Thread Size | M10 x 1 |
| Cable Type | Armored |
| Total Length | 0.5 m |
| Connector Type | Miniature coaxial ClickLoc |
| Agency Approvals | CSA, ATEX, IECEx |
Ensure the probe is gapped correctly according to the system manual for the specific machinery application. Use the provided connector protector to prevent contamination of the coaxial connection. Armored probes should be secured using compatible M10 mounting brackets; ensure the armor is routed away from high-vibration sources to prevent fatigue. For hazardous area installations, adhere strictly to the entity parameters and control drawings associated with the CSA, ATEX, and IECEx certifications.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330104-00-08-05-01-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
