Configuration options for the 330104-00-08-10-02-05 3300 XL 8 mm proximity probe include a 0.0 mm unthreaded length (Option 00), 80 mm case length (Option 08), 1.0 m system length (Option 10), standard ClickLoc connector (Option 02), and hazardous area agency approvals (Option 05). This probe is designed for harsh industrial environments, featuring a durable M10 x 1 threaded body with integral armor to protect the cable assembly from mechanical damage.
The 3300 XL 8 mm proximity transducer system, which includes this probe, the 330180 Proximitor sensor, and a matched extension cable, is a non-contact eddy-current displacement measurement system. It provides precise shaft vibration and axial position measurement for critical rotating machinery. The 330104 model is specifically designed for applications where threaded mounting in an M10 x 1 port is required and armored cable is necessary for environmental protection.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330104-00-08-10-02-05 | 3300 XL 8 mm Proximity Probe, M10 x 1, Armored |
| A - Unthreaded Length | 00 | 0.0 mm (fully threaded) |
| B - Case Length | 08 | 80 mm |
| C - Total Length | 10 | 1.0 m |
| D - Connector | 02 | Miniature coaxial ClickLoc, standard cable |
| E - Agency Approval | 05 | CSA, ATEX, IECEx Approvals |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model / Part Number | 330104-00-08-10-02-05 |
| Probe Diameter | 8 mm |
| Thread Type | M10 x 1 |
| Cable Type | Armored |
| Total Length | 1.0 m |
| Connector | Miniature coaxial ClickLoc |
| Agency Approvals | CSA, ATEX, IECEx |
Ensure the probe is installed using the appropriate threaded mounting bracket (e.g., M10 x 1 compatible) to maintain proper sensing gap. The system must be calibrated as a complete chain (probe, extension cable, and Proximitor sensor) to ensure linear output. For hazardous area installations, follow the specific Bently Nevada installation drawings (e.g., 141092 for ia, 140979 for nA/ec) to maintain certification compliance. Protect the connector assembly from moisture and contaminants using the provided connector protector if applicable.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330104-00-08-10-02-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
