Description

The 330104-00-13-10-02-00 is an 8 mm M10 x 1 thread proximity probe from the Bently Nevada 3300 XL series, configured with an armored cable for enhanced mechanical protection. This eddy-current displacement transducer is engineered for high-precision, non-contact measurement of shaft vibration and axial position on critical rotating machinery. The 1.0 m total system length and ClickLoc connector facilitate integration into standard 3300 XL monitoring chains, pairing directly with 3300 XL Proximitor sensors and extension cables.

This specific configuration features 0 mm of unthreaded length (Option 00) and a 130 mm case length (Option 13), providing a robust mechanical fit for applications where abrasion resistance is required due to the inclusion of the armored cable (Option 02 connector type). The system is designed to operate without specific hazardous area agency approvals (Option 00), making it suitable for standard industrial environments requiring non-contact displacement monitoring.

Features

• M10 x 1 thread stainless steel probe body with protective armor
• 0 mm unthreaded length and 130 mm total case length for precise mounting
• 1.0 m total probe length for standard proximity transducer system chains
• Miniature ClickLoc coaxial connector with standard interface
• Non-contact eddy-current technology suitable for continuous shaft vibration and axial position monitoring
• Compatible with 3300 XL 8 mm Proximitor sensor and extension cable systems

Applications

• Critical machinery protection (turbines, compressors, pumps)
• Shaft vibration and rotor position measurement
• Applications requiring abrasion resistance (armored cable)
• Standard monitoring chains in non-hazardous environments

Ordering Information

Technical Specifications

Installation Guidelines

Ensure the probe is gapped correctly according to the 3300 XL system manual to maintain the linear measurement range. When installing, verify the armored cable is routed to prevent strain on the connector interface. Ensure the Proximitor sensor is mounted in a dry, protected environment (IP54 or better) if not enclosed in a protective housing. Tighten the probe mounting threads securely, ensuring the assembly meets torque specifications for the M10 x 1 thread to maintain signal integrity.

Compliance and Certifications

This unit is supplied without hazardous area approvals (Option 00). For installations requiring safety compliance, ensure the transducer system meets the site-specific requirements for vibration monitoring equipment.
