The 330103-00-05-05-02-CN is an 8 mm proximity probe from the 3300 XL series, featuring an M10 x 1 thread and a non-armored construction. This specific configuration includes a 0.0 inch unthreaded length (Option 00), a 0.5 inch case length (Option 05), and a 0.5 meter total system length (Option 05). It is equipped with a miniature coaxial ClickLoc connector and standard cable (Option 02) and is supplied with the China hazardous area approval package (-CN), which includes NEPSI and CCC certifications.
The 3300 XL 8 mm transducer system is designed for non-contact eddy-current displacement measurement, serving as a primary component in shaft vibration and axial position monitoring chains for critical rotating machinery. The system is fully compatible with 3300 XL Proximitor sensors and extension cables, providing reliable signal transmission in demanding industrial environments.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-00-05-05-02-CN | 3300 XL 8 mm Proximity Probe, M10 x 1 thread, non-armored |
| A - Unthreaded Length | 00 | 0.0 in (0.0 mm) |
| B - Case Length | 05 | 0.5 in (approx. 12.7 mm) |
| C - Total Length | 05 | 0.5 meter |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| Suffix -CN | -CN | China hazardous area approval package (NEPSI + CCC) |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330103-00-05-05-02-CN |
| Probe Diameter | 8.0 mm |
| Thread Type | M10 x 1 |
| Cable Type | Standard (non-armored) |
| Total Length | 0.5 m |
| Connector | Miniature coaxial ClickLoc |
| Operating Temperature | -52 degC to +177 degC |
| Agency Approvals | NEPSI, CCC (via -CN suffix) |
Ensure the probe is installed with adequate clearance from surrounding metallic surfaces to prevent interference. The M10 x 1 thread requires careful engagement; do not exceed the recommended maximum thread engagement length of 15 mm to avoid binding. Use proper torque settings for connector mating to ensure signal integrity. For hazardous area installations, adhere to local requirements associated with the included NEPSI and CCC certifications.
This product includes the -CN suffix, signifying compliance with China hazardous area approval standards, including NEPSI and CCC. Ensure the installation meets all relevant regional safety and electrical codes for hazardous locations.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-05-05-02-CN
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
