Option 040 (4.0 meters length) and Option 00 (standard cable without connector protector) define this 3300 XL Standard Extension Cable configuration — 330130-040-00-00.
This standard unarmored version contrasts with armored (-01) or connector-protected (-02) variants by offering lightweight, highly flexible routing in environments where mechanical crushing or extreme abrasion risks are minimized. It provides the essential electrical connection between a 3300 XL 8 mm proximity probe and a Proximitor sensor, completing a 5.0-meter or 9.0-meter monitoring loop. When combined with a 1.0-meter probe, it achieves a total system length of 5.0 meters, which matches the calibration of a standard 5-meter Proximitor sensor.
Typical heavy-industry scenarios include steam and gas turbine shaft vibration measurement, generator bearing housing monitoring, industrial gearbox alignment tracking, and electric motor shaft displacement analysis within Bently Nevada 3300 XL 8 mm transducer setups.
| Option Segment | Option Code | Meaning from PDF |
|---|---|---|
| Orderable Part Number | 330130-040-00-00 | 3300 XL Standard Extension Cable, 4.0 m, standard cable, no approvals |
| A - Cable Length Option | 040 | 4.0 meters (13.1 feet) |
| B - Connector Protector and Cable Option | 00 | Standard cable (no connector protector) |
| C - Agency Approval Option | 00 | Not required (general purpose use) |
| Manufacturer | Bently Nevada |
| Part Number / Model | 330130-040-00-00 |
| Transducer Compatibility | 3300 XL 8 mm Proximity Transducer System |
| Cable Length | 4.0 m (13.1 ft) |
| Cable Type | Standard coaxial cable (unarmored) |
| Connector Type | Gold-plated brass miniature coaxial ClickLoc connectors (one male, one female) |
| Cable Outside Diameter | 3.68 mm (0.145 in) nominal |
| Insulation Material | FEP (Fluorinated Ethylene Propylene) |
| Minimum Bend Radius | 25.4 mm (1.0 in) |
| Operating Temperature Range | -52 degC to +177 degC (-62 degF to +350 degF) |
| Weight | 0.14 kg |
| Dimensions | 150 mm x 150 mm x 25 mm (H x W x D) |
| Connector Type | Connection Target | Coupling Method |
|---|---|---|
| Miniature Male ClickLoc | Proximitor Sensor input | Finger-tight connection |
| Miniature Female ClickLoc | Proximity Probe connector | Finger-tight connection |
Avoid routing cables near high-voltage lines or AC electrical noise sources. Tighten ClickLoc connectors finger-tight until an audible click is felt; do not use tools or pliers unless joining non-XL connectors. Pull cables carefully through conduit, avoiding sharp bends or excess pulling tension. Maintain a bend radius of at least 25.4 mm (1.0 in) along the entire cable run to prevent impedance mismatch or mechanical fatigue.
This General Purpose option (CC=00) does not carry specific hazardous area certification markings. It is intended for installation in non-classified, general purpose industrial environments.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330130-040-00-00
Country of origin:United States
Product Type: 3300 XL Standard Extension Cable
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 150 mm x 150 mm x 25 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
