The 330130-080-03-00 is an 8.0-meter 3300 XL standard extension cable designed for use in 3300 XL 8 mm proximity transducer systems. This configuration features an armored cable with a connector protector (Option 03) to provide mechanical protection and ensure connector integrity in industrial environments. It facilitates reliable signal transmission between the probe and the Proximitor sensor, ensuring the total length requirements of the transducer system are met for accurate shaft vibration and position monitoring.
The 3300 XL extension cable is engineered to maintain high signal fidelity in demanding applications such as turbine, compressor, and pump monitoring. The inclusion of an armored jacket offers enhanced resistance to abrasion and physical damage, while the connector protector shields the miniature coaxial ClickLoc connectors from contamination and moisture ingress. This cable is fully compatible with standard 3300 XL Proximitor sensors and probes, provided the total system length (probe + cable) matches the calibrated Proximitor length.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330130-080-03-00 | 3300 XL Standard Extension Cable |
| A - Cable Length | 080 | 8.0 meters (26.2 feet) |
| B - Cable/Connector | 03 | Armored cable with connector protector |
| C - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330130-080-03-00 |
| Product Type | 3300 XL Standard Extension Cable |
| Cable Length | 8.0 m (26.2 ft) |
| Cable Type | Armored |
| Connector Protector | Included |
| Connectors | Miniature coaxial ClickLoc |
| Agency Approvals | None (Option 00) |
Ensure that the sum of the extension cable length and the probe length equals the rated length of the Proximitor sensor (e.g., 5.0 meters or 9.0 meters). When installing armored cables, avoid sharp bends that could compromise the integrity of the armor or the internal signal conductor. Use connector protectors to seal the connection point between the probe lead and the extension cable if the environment poses a risk of moisture or oil ingress.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330130-080-03-00
Country of origin:United States
Product Type: 3300 XL Standard Extension Cable
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
