The 330130-085-00-05 is a 3300 XL 8 mm standard extension cable designed for use in 3300 XL proximity transducer systems. This configuration features an 8.5 meter (27.9 feet) total length, standard cable construction (Option 00), and CSA, ATEX, IECEx agency approvals (Option 05). It facilitates essential signal transmission between the proximity probe and the Proximitor sensor, ensuring compatibility within machinery protection monitoring loops.
The 3300 XL standard extension cable ensures that system length requirements are met when paired with compatible 3300 XL probes and sensors. The ClickLoc connectors provide reliable, secure connections, while the standard cable configuration (Option 00) is suitable for typical industrial environments where armor protection is not specifically required. Users must verify that the combined probe and extension cable length matches the total length required by the associated Proximitor sensor for accurate system calibration.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330130-085-00-05 | 3300 XL Standard Extension Cable |
| A - Cable Length | 085 | 8.5 meters (27.9 feet) |
| B - Cable Option | 00 | Standard cable |
| C - Agency Approval | 05 | CSA, ATEX, IECEx Approvals |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330130-085-00-05 |
| System Type | 3300 XL 8 mm Proximity Transducer System |
| Cable Length | 8.5 meters (27.9 feet) |
| Cable Type | Standard |
| Connector | Miniature coaxial ClickLoc |
| Agency Approvals | CSA, ATEX, IECEx |
Ensure that the extension cable is routed to prevent physical damage and minimize interference from external electromagnetic sources. Maintain the minimum permissible cable bend radius to protect the signal integrity of the coaxial cable. When connecting to the Proximitor sensor and probe, ensure all ClickLoc connectors are fully seated and free of contaminants. It is recommended to perform system calibration checks after installation to ensure the total system length aligns with the Proximitor sensor settings.
This product meets the requirements for hazardous area installations as specified by the Option 05 certification, which includes CSA, ATEX, and IECEx approvals. Always verify current site safety requirements and area classification before installation.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330130-085-00-05
Country of origin:United States
Product Type: 3300 XL Standard Extension Cable
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
