330851-02-000-060-50-00-00: 3300 XL 25 mm proximity probe, M30x2 thread, Option 000 fully threaded metric case, Option 060 60 mm overall case length, Option 50 5.0 m total system length, Option 00 standard unarmored coaxial cable, Option 00 no agency approvals.
This specific configuration incorporates an M30x2 metric thread (Option 02) and a 60 mm overall case length that is completely threaded (0.0 mm unthreaded). Operating as an eddy-current displacement sensor, this probe integrates with a 3300 XL 25 mm Proximitor sensor and a 3300 XL extension cable to measure large-target displacement. The integrated 5.0-meter PFA-insulated triaxial FluidLoc cable (Option 50) features front and rear seals that work together with the cable jacket to prevent moisture from entering the probe tip, maintaining electrical integrity in humid and harsh conditions. The clickLoc connector on the probe lead has a removable collar to simplify routing through tight clearances.
| Option / Segment | Code on This SKU | Description / Meaning |
|---|---|---|
| Base Model | 330851 | 3300 XL 25 mm Proximity Probe |
| A: Probe Case Type Option | 02 | M30x2 thread (Metric, supplied with 38 mm lock nut and 27 mm wrench flats) |
| B: Unthreaded Length Option | 000 | 0 mm unthreaded length (fully threaded) |
| C: Overall Case Length Option | 060 | 60 mm overall case length |
| D: Total Length Option | 50 | 5.0 metres (16.4 feet) system length |
| E: Armor Option | 00 | No Armor (PFA-insulated jacket only) |
| F: Agency Approval Option | 00 | No Approvals (for use in general/non-hazardous areas) |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number / Model | 330851-02-000-060-50-00-00 |
| System Type | 3300 XL 25 mm Proximity Transducer System |
| Linear Range | 12.7 mm (500 mils) starting at 0.63 mm (25 mils) from target |
| Average Scale Factor (ASF) | 0.787 V/mm (20 mV/mil) nominal |
| Deviation from Best Fit Straight Line (DSL) | Less than +/-0.31 mm (+/-12 mils) |
| Frequency Response | 0 to 2.7 kHz: +0, -3 dB typical (with up to 305 m of field wiring) |
| Recommended Minimum Target Size | 61 mm (2.4 in) diameter (flat target) |
| Case Thread Size | M30x2 metric thread |
| Unthreaded Length | 0.0 mm (fully threaded) |
| Case Length | 60 mm |
| Total Probe Length | 5.0 meters (16.4 feet) |
| Cable Material | 75 ohm triaxial, perfluoroalkoxyethylene (PFA) insulated FluidLoc probe cable |
| Probe Tip Material | Polyetheretherketone (PEEK) |
| Probe Case Material | AISI 304 stainless steel (SST) |
| Armor Option | No armor (standard outer PFA jacket only) |
| Probe DC Resistance (RPROBE) | 7.5 +/- 0.8 ohms (center conductor to outer conductor for 5.0 m length) |
| Lock Nut Wrench / Size | 38 mm lock nut and 27 mm wrench flats |
| Connector-to-Connector Torque | Finger tight recommended; maximum torque 0.565 N-m (5 in-lb) |
| Environmental Limits (Probe Temperature) | Operating and Storage: -35 degC to +200 degC (-31 degF to +392 degF); Short-term: +250 degC (482 degF) max for less than 24 hours |
| Relative Humidity | 100% condensing, non-submersible when connectors are protected |
| Agency Approvals Option | Option 00 (No Approvals) |
| Interface Component | Specification / Type |
|---|---|
| Probe Lead Connector | Gold-plated miniature ClickLoc coaxial female connector with removable nut collar |
| Extension Cable Interface | Connects to 3300 XL 25 mm extension cable (such as model 330854) |
| Connector Material | Gold-plated brass and gold-plated beryllium copper |
Ensure standard installation practices are followed for optimal transducer system operation:
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330851-02-000-060-50-00-00
Country of origin:United States
Product Type: 3300 XL 25 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 350g
Dimensions: 70 mm x 120 mm x 120 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
