330902-00-12-10-02-05: 3300 XL NSv proximity probe, 1/4-28 UNF thread with armor (Option 00 unthreaded length, Option 12 case length, Option 10 total length, Option 02 connector, Option 05 agency approval). This 3300 NSv transducer is specifically engineered for applications with limited target area or tight clearance requirements, providing reliable non-contact eddy-current displacement measurement for machinery monitoring.
As part of the 3300 XL NSv Proximity Transducer System, this probe is compatible with the 330980 Proximitor Sensor and 330930 extension cable. The system is designed to maintain consistent scale factors in small-bore machinery and high-speed equipment where standard 3300 XL 8 mm probes are unsuitable due to physical size constraints.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330902-00-12-10-02-05 | 3300 NSv Proximity Probe, 1/4-28 UNF, with armor |
| A - Unthreaded Length | 00 | 0.0 in |
| B - Case Length | 12 | 1.2 in |
| C - Total Length | 10 | 1.0 m |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 05 | Multiple approvals (CSA, ATEX, IECEx) |
| Manufacturer | Bently Nevada |
| Part Number | 330902-00-12-10-02-05 |
| Probe Diameter | 1/4-28 UNF-2A |
| Probe Material | Polyphenylene sulfide (PPS) tip |
| Case Material | AISI 304 stainless steel (SST) |
| Cable Type | 75 Ohm coaxial, FEP insulated |
| Connector | Miniature coaxial ClickLoc |
| System Length | 1.0 meter (total) |
| Agency Approvals | CSA, ATEX, IECEx |
| Temperature Range (Storage) | -55 degC to +105 degC |
Ensure the probe is installed in accordance with Bently Nevada installation drawings for the corresponding hazardous area classification. Proper isolation from the machine housing ground is required, typically achieved using mounting pads for the Proximitor Sensor. Use silicone self-fusing tape to protect connectors from environmental ingress if not using factory-provided connector protectors.
This product meets the requirements of the 3300 XL NSv system as defined in the datasheet. Approvals include CSA (Class I, Div 2), ATEX, and IECEx for hazardous locations, subject to specific temperature schedules and installation drawings.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330902-00-12-10-02-05
Country of origin:United States
Product Type: Sonde di prossimità 3300 NSv
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 120g
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
