The 330905-00-03-10-02-00 is a 3300 XL NSv proximity probe designed for machinery vibration and position monitoring in applications with restricted target areas or tight clearances. As a core component of the 3300 XL NSv proximity transducer system, this probe provides linear, non-contact measurement of shaft displacement, essential for monitoring aeroderivative gas turbines and small-bore rotating equipment. This specific configuration features an M10x1 thread, a 0.0 in unthreaded length (Option 00), and a 0.3 in case length (Option 03).
The transducer system uses a 1.0 m total length (Option 10) and is equipped with a miniature coaxial ClickLoc connector (Option 02) for secure, reliable attachment to the matching extension cable. The system is designed for environments where standard-sized probes may be physically unsuitable due to target size or mounting constraints, utilizing advanced eddy-current technology to maintain measurement accuracy without contact. This variant is provided without agency approvals (Option 00) for standard non-hazardous area applications.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330905-00-03-10-02-00 | 3300 NSv Proximity Probe, M10X1 Thread |
| A - Unthreaded Length | 00 | 0.0 in unthreaded |
| B - Case Length | 03 | 0.3 in case length |
| C - Total Length | 10 | 1.0 m (39 in) |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada |
| Part Number | 330905-00-03-10-02-00 |
| Probe Type | 3300 NSv Proximity Probe |
| Thread Size | M10x1 |
| Armor | Without armor |
| Total Length | 1.0 m |
| Connector | Miniature coaxial ClickLoc |
| Cable Type | Standard |
| Probe Tip Material | Ryton (PPS) |
| Operating Temperature | -55 degC to +177 degC |
| Agency Approvals | Not required (Option 00) |
Ensure correct probe gap settings according to the machinery monitoring requirements. Use the supplied lock nut for secure mounting. When installing the ClickLoc connector, ensure it is clean and hand-tightened to prevent signal interference or moisture ingress. For optimal performance, follow standard Bently Nevada grounding and shielding practices as detailed in the system documentation. Connector protectors are recommended for environments exposed to fluid or high humidity.
This product configuration complies with the following directives for non-hazardous applications: EN 61000-6-2 (Immunity for Industrial Environments) and EN 61000-6-4 (Emissions for Industrial Environments). RoHS compliant per Directive 2011/65/EU.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330905-00-03-10-02-00
Country of origin:United States
Product Type: 3300 NSv Proximity Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 120g
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
