The 330905-00-05-05-05-02-05 is a 3300 XL NSv proximity probe configured with a 5 mm tip diameter, M10x1 threads, and specialized cable options for compact installation. This transducer component is part of the 3300 XL NSv system, which is specifically engineered for high-speed machinery, aeroderivative gas turbines, and other rotating equipment where target space or side-view restrictions prevent the use of standard 8 mm proximity transducer systems.
This 3300 NSv probe operates in conjunction with a 330980 Proximitor sensor and a 330930 extension cable to deliver accurate, non-contact measurement of radial vibration, axial thrust position, and tachometer signals. The probe design is optimized for small-bore machinery and applications involving small target areas, maintaining linear performance where larger probes would otherwise experience significant scale factor changes.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330905-00-05-05-05-02-05 | 3300 XL NSv Proximity Probe, M10x1 Thread |
| A - Unthreaded Length | 00 | 0.0 inch unthreaded length |
| B - Overall Case Length | 05 | 0.5 inch case length |
| C - Total System Length | 05 | 0.5 meter (20 inch) |
| D - Connector / Cable | 05 | Configuration specific (Refer to datasheet) |
| E - Agency Approval | 02 | Configuration specific |
| F - Suffix | 05 | Multiple Agency Approvals (CSA, ATEX, IECEx) |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330905-00-05-05-05-02-05 |
| Probe Diameter | 5 mm |
| Thread Size | M10x1 |
| Case Material | AISI 304 stainless steel |
| Tip Material | Polyphenylene sulfide (PPS) |
| System Length | 0.5 meter |
| Operating Temperature | -55 degC to +177 degC |
| Agency Approvals | CSA, ATEX, IECEx |
Ensure the probe is installed with adequate clearance from surrounding metal to maintain the specified scale factor. The system must be connected to a Bently Nevada 3300 XL NSv Proximitor sensor using a compatible 330930 extension cable. Maintain proper cable routing to prevent signal interference and mechanical damage. For hazardous area installations, adhere to local safety requirements and Bently Nevada installation drawings.
This product meets European Community Directive 2014/30/EU (EMC Directive) and 2011/65/EU (RoHS Directive). It complies with SIL 2 functional safety standards (HFT=0) and carries hazardous area certifications including ATEX, IECEx, and CSA ratings for explosive atmospheres.
