330905-00-10-10-02-00 is a 3300 XL NSv proximity probe configured for standard mounting with a 0.0 in (0.0 mm) unthreaded length (Option 00), 1.0 in (25 mm) case length (Option 10), and a 1.0 m (3.3 ft) total length (Option 10). This 5 mm diameter probe utilizes a miniature coaxial ClickLoc connector (Option 02) and requires no agency approval (Option 00). The 3300 XL NSv (Near-field Sensing) transducer system is specifically engineered for applications involving small-target geometry or limited installation space where standard 8 mm probes cannot be effectively mounted.
The NSv system allows for accurate displacement measurement on small-bore machinery, such as aeroderivative turbines and high-speed equipment, by reducing the electromagnetic field spread. The system components, including this probe, must be used with the 330980 Proximitor sensor and 330930 extension cable to ensure correct system calibration and linear output. The 330905 probe incorporates a proprietary tip design that maintains linear output even when sensing surfaces are smaller than the standard probe diameter.
| Orderable Part Number | 330905-00-10-10-02-00 | 3300 XL NSv Proximity Probe |
| A - Unthreaded Length | 00 | 0.0 in (0.0 mm) |
| B - Case Length | 10 | 1.0 in (25 mm) |
| C - Total Length | 10 | 1.0 m (3.3 ft) |
| D - Connector | 02 | Miniature coaxial ClickLoc connector |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada |
| Part Number | 330905-00-10-10-02-00 |
| Probe Diameter | 5 mm |
| Total Length | 1.0 m |
| Connector Type | Miniature ClickLoc |
| System Compatibility | 330980 Proximitor Sensor, 330930 Extension Cable |
| Linear Range | 1.5 mm (60 mil) |
| Operating Temperature | -35 degC to +177 degC |
The 330905 probe should be installed using the recommended mounting brackets to ensure stability. Verify that the target material is compatible with the transducer calibration (typically AISI 4140 steel). Maintain appropriate clearance for the probe tip to prevent mechanical impact. Secure the coaxial cable using industrial-grade cable ties to minimize vibration-induced noise, and ensure that the ClickLoc connector is fully engaged and protected from environmental contaminants if installed in non-enclosed areas.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330905-00-10-10-02-00
Country of origin:United States
Product Type: 3300 NSv Proximity Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 120g
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
