Bently Nevada 330905-00-10-10-02-05 3300 XL NSv Sonda di prossimità

SKU 330905-00-10-10-02-05

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Bently Nevada
Product No.: 330905-00-10-10-02-05
Origin United States
Product Type: Sonde di prossimità 3300 NSv
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 0.12 kg
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Quantità

Call sales Contact

Product Description

Description

The 330905-00-10-10-02-05 3300 XL NSv proximity probe is designed for use in 3300 XL NSv proximity transducer systems, providing non-contact displacement measurement for machinery monitoring. This specific configuration features a 0.0 in unthreaded length (Option 00), 1.0 in case length (Option 10), 1.0 m system length (Option 10), and utilizes a Miniature ClickLoc connector with standard cable (Option 02), meeting hazardous area approval requirements (Option 05).

Engineered for applications with small target areas or limited radial clearance, this probe operates in tandem with the 330980 NSv Proximitor sensor and 330930 extension cable to form a complete monitoring chain. The NSv system delivers linear output signals proportional to the distance between the probe tip and the observed conductive surface, making it suitable for axial position and radial vibration monitoring on small-bore machinery or high-speed equipment where standard 8 mm probes are physically constrained.

Features

Option 00 (0.0 in) unthreaded case length configuration for flush mounting requirements.
Option 10 (1.0 in) case length provides stable housing for installation in tight clearance areas.
Option 02 (Miniature ClickLoc) connector compatible with standard 3300 XL NSv cabling interfaces.
Option 05 provides CSA, ATEX, and IECEx approvals for use in hazardous environments.
Compact 5 mm probe tip diameter optimized for small-target sensitivity.

Applications

Small-bore rotating machinery monitoring.
Aeroderivative gas turbines and auxiliary equipment.
High-speed centrifugal compressors and blowers with limited installation space.
Vibration and position analysis where target geometry restricts the use of 8 mm or 11 mm probes.

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330905-00-10-10-02-05	3300 XL NSv Proximity Probe
A - Unthreaded Length	00	0.0 in
B - Case Length	10	1.0 in
C - Total Length	10	1.0 m
D - Connector/Cable	02	Miniature ClickLoc, standard cable
E - Agency Approval	05	CSA, ATEX, IECEx

Technical Specifications

Manufacturer	Bently Nevada
Part Number	330905-00-10-10-02-05
Probe Tip Diameter	5 mm
System Compatibility	3300 XL NSv Proximitor Sensor (330980)
Connector Type	Miniature ClickLoc
Total System Length	1.0 m
Agency Approvals	CSA, ATEX, IECEx

Installation Guidelines

Ensure the probe tip is installed in a non-conductive mounting fixture or properly isolated if the machine case is conductive to prevent ground loops.
Maintain the specified physical gap between the probe tip and the target as defined by the NSv system calibration curve.
Use the appropriate extension cable length to ensure the total system length (Probe + Cable) matches the Proximitor sensor calibration (1.0 m).
Route cables away from high-power conduits or electromagnetic interference sources to maintain signal integrity.

Compliance and Certifications

CSA (Canadian Standards Association) Certified
ATEX (Atmospheres Explosibles) Compliant
IECEx (International Electrotechnical Commission System for Certification to Standards Relating to Equipment for Use in Explosive Atmospheres)

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

Che cosa indica la designazione NSv per questa sonda 330905?

La designazione NSv (Non-contact Small-view) indica che questa sonda è ottimizzata specificamente per macchinari con alberi di piccolo diametro o per applicazioni con accesso limitato, dove una sonda standard da 8 mm sarebbe fisicamente troppo grande o avrebbe un campo di rilevamento troppo ampio.

La 330905-00-10-10-02-05 è compatibile con i Proximitor standard 3300 XL da 8 mm?

No, questa sonda deve essere utilizzata con il sensore Proximitor 330980 NSv. Non è elettricamente compatibile con i sensori Proximitor standard 3300 XL da 8 mm a causa delle differenze nella progettazione della bobina di rilevamento e nei requisiti di linearità dell'uscita.

Che cosa rappresenta l'opzione 02 nella stringa dell'ordine?

L'opzione 02 specifica che la sonda è dotata di un connettore Miniature ClickLoc e di un cavo standard. Questo connettore è specifico della linea di prodotti NSv ed è più piccolo dei connettori standard utilizzati sulle sonde da 8 mm.

Questa sonda può essere utilizzata in aree pericolose?

Sì, l'opzione 05 nel numero di modello indica che questa sonda soddisfa i requisiti di approvazione CSA, ATEX e IECEx per aree pericolose.
