330905-00-12-10-02-05: 3300 XL NSv proximity probe, M10x1 thread, non-armored (Option 00), with 1.2 in case length (Option 12), 1.0 m total length (Option 10), and standard miniature coaxial ClickLoc connector (Option 02) with multiple agency approvals (Option 05). This configuration is optimized for non-contact displacement measurement in tight clearance or reduced-target applications, typical of small-bore machinery and aeroderivative turbine monitoring.
The 3300 XL NSv Proximity Transducer System is engineered to deliver reliable radial vibration and axial position data in environments where standard probe sizes are restricted. This non-armored variant utilizes the M10x1 threaded stainless steel body to provide structural compatibility with standard mounting requirements while ensuring the precise sensing characteristics of the NSv family. The inclusion of Option 05 approvals (CSA, ATEX, IECEx) ensures compliance with hazardous area regulations for global installations.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330905-00-12-10-02-05 | 3300 NSv Probe, M10x1 thread, without armor |
| A - Unthreaded Length | 00 | 0 mm (per datasheet configuration rules) |
| B - Case Length | 12 | 1.2 in |
| C - Total Length | 10 | 1.0 m |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 05 | Multiple Approvals (CSA, ATEX, IECEx) |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330905-00-12-10-02-05 |
| Probe Type | 3300 XL NSv Proximity Probe |
| Thread Size | M10x1 |
| Armor | None (Non-armored) |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 304 stainless steel |
| Total Length | 1.0 m |
| Connector | Miniature coaxial ClickLoc |
| Operating Temperature | -55 degC to +177 degC (probe) |
| Agency Approvals | Multiple (CSA, ATEX, IECEx) |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330905-00-12-10-02-05
Country of origin:United States
Product Type: 3300 NSv Proximity Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 120g
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
