330909-00-20-10-01-05: 3300 NSv Proximity Probe configured with a 3/8-24 UNF-2A thread, stainless steel armor, 0.0 inches unthreaded case length, 2.0 inches overall case length, 1.0 meter total length, miniature ClickLoc coaxial connector with connector protector, and multiple hazardous area approvals.
This 3300 NSv eddy-current probe is used in limited clearance and narrow target applications where standard 8 mm probes are unsuitable. The integrated AISI 302 stainless steel armor provides robust mechanical protection for the FEP insulated cable in demanding industrial environments. Equipped with a ClickLoc connector and a fluorosilicone connector protector, it ensures secure coaxial coupling and protection against environmental contaminants like oil and moisture.
| Option Code | This SKU Value | Description / Option Meaning |
|---|---|---|
| Base Model | 330909 | 3300 NSv Proximity Probe, 3/8-24 UNF thread, with stainless steel armor |
| A - Unthreaded Length | 00 | 0.0 in (0 mm) unthreaded length |
| B - Overall Case Length | 20 | 2.0 in (51 mm) overall case length |
| C - Total Length | 10 | 1.0 meter (39 in) total length |
| D - Connector and Cable Type | 01 | Miniature coaxial ClickLoc connector with connector protector, standard FEP cable |
| E - Agency Approval | 05 | Multiple approvals (CSA, ATEX, IECEx, etc.) |
| Manufacturer | Bently Nevada |
| Part Number / SKU | 330909-00-20-10-01-05 |
| System Compatibility | 3300 XL NSv Transducer System |
| Thread Size | 3/8-24 UNF-2A |
| Armor Material | Flexible AISI 302 stainless steel (SST) |
| Probe Tip Diameter | 5.26 mm (0.207 in) |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 304 stainless steel (SST) |
| Cable Insulation | Fluoroethylene propylene (FEP) insulated coaxial cable |
| System Linear Range | 1.5 mm (60 mils), typical range from 0.25 to 1.75 mm (10 to 70 mils) |
| Average Scale Factor | 7.87 V/mm (200 mV/mil) |
| Recommended Gap | 1.0 mm (40 mils) |
| Frequency Response | 0 to 10 kHz: +0, -3 dB typical |
| Operating/Storage Temperature | -52 degC to +177 degC |
| Relative Humidity | 100% condensing, non-submersible when connectors are protected |
| Pressure Sealing | Viton O-ring pressure seal between tip and case |
| Tensile Strength | 220 N (50 lb) maximum rated probe case to probe lead / lead to extension cable |
Ensure the probe is gapped correctly to 1.0 mm (40 mils) using the appropriate DC voltage output (-9.0 Vdc nominal) from the Proximitor sensor. During installation of the armored probe, maintain a minimum bend radius of 25.4 mm (1.0 in) for the armored cable. To prevent cross-talk when multiple probes are installed in parallel, maintain a minimum separation of 25 mm (1.0 in) between probe tips for axial position measurements, or 23 mm (0.9 in) for radial vibration measurements. Tighten 3/8-24 probe cases to a maximum recommended torque of 11.3 N m (100 in-lb).
The 3300 NSv Transducer System carries certifications under hazardous area approvals when specified with the Option 05 package, including:
