Bently Nevada 330930-060-00-CN 3300 NSv Extension Cable

SKU 330930-060-00-CN

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Bently Nevada
Product No.: 330930-060-00-CN
Origin United States
Product Type: 3300 NSv Extension Cable
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 0.12 kg
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Quantità

Call sales Contact

Product Description

Description

Option 060 (6.0 m cable length) and Option 00 (without stainless steel armor) specify this 3300 NSv extension cable configuration — 330930-060-00-CN.

This unarmored coaxial cable connects a 3300 NSv proximity probe to a 330980 Proximitor sensor in non-contact eddy-current displacement measurement loops. The -CN suffix indicates compliance with the China hazardous area approval package, certifying the assembly under NEPSI and CCC regulations for use in classified industrial zones.

Features

Option 060 cable length provides a 6.0-meter (19.7 feet) physical extension.
Option 00 specifies a standard unarmored configuration, suitable for installations utilizing protective conduits.
Standard 75-ohm coaxial design maintains signal impedance and limits transmission loss.
Equipped with miniature coaxial ClickLoc connectors at both ends for reliable plug-and-play connections.
Suffix -CN delivers NEPSI and CCC China hazardous area approval compliance.

Applications

This extension cable is used in systems monitoring small-bore machinery, aeroderivative gas turbines, and high-speed industrial equipment with limited target geometry. Typical industrial sectors include:

Power generation turbine systems
Petrochemical and oil and gas processing facilities
Centrifugal and axial compressor monitoring
High-speed rotating machinery with tight target constraints

Ordering Information

Option Segment	Code on This SKU	Description
Orderable Part Number	330930-060-00-CN	3300 NSv Extension Cable, 6.0 meters, unarmored, China approvals
A - Cable Length	060	6.0 meters (19.7 feet)
B - Connector and Cable	00	Without stainless steel armor
Suffix	-CN	China hazardous area approval package (NEPSI + CCC + markings)

Technical Specifications

Parameter	Specification Value
Manufacturer	Bently Nevada (Baker Hughes)
Model / Part Number	330930-060-00-CN
System Compatibility	3300 XL NSv Proximity Transducer System
Cable Length	6.0 meters (19.7 feet)
Armor Option	Without stainless steel armor (Option 00)
Impedance	75 ohm
Extension Cable Capacitance	69.9 pF/m (21.3 pF/ft) typical
Center Conductor Resistance	0.220 ohm/m (0.067 ohm/ft)
Shield Resistance	0.066 ohm/m (0.020 ohm/ft)
Minimum Bend Radius	25.4 mm (1.0 in)
Operating and Storage Temperature	-52 degC to +177 degC (-62 degF to +351 degF)
Relative Humidity	100% condensing, non-submersible when connectors are protected

Connections and Interfaces

Connector Component	Type and Material
Probe End Connection	Miniature coaxial ClickLoc connector (female socket)
Proximitor End Connection	Miniature coaxial ClickLoc connector (male plug)
Connector Material	Gold-plated brass
Connection Torque	Finger tight recommended, 0.56 N m maximum

Installation Guidelines

Maintain a minimum bend radius of 25.4 mm (1.0 in) during routing to prevent core or shield damage.
Ensure the total electrical length of the probe and extension cable matches the calibrated length of the 3300 XL NSv Proximitor Sensor (e.g., 5.0 m or 7.0 m system length).
Protect connectors from ingress of moisture, turbine oil, and other contaminants by utilizing connector protectors or silicone self-fusing tape (such as part number 03200006) on the connections.
Route cables through conduit where mechanical protection is required, since this configuration (Option 00) does not feature stainless steel armor.

Compliance and Certifications

CCC (China Compulsory Certification)
NEPSI (National Supervision and Inspection Centre for Explosion Protection and Safety of Instrumentation)
ATEX/IECEx (Intrinsically safe Ex ia IIC, non-sparking Ex nA/ec IIC)
CE Directive compliance (EMC 2014/30/EU, RoHS 2011/65/EU)
SIL 2 / SIL 3 functional safety rated

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the physical length of the 330930-060-00-CN extension cable?

This cable has a physical length of 6.0 meters (19.7 feet), which is defined by the 060 option segment.

Does the 330930-060-00-CN cable include physical armor protection?

No, the 00 option code indicates that this cable configuration is without stainless steel armor, making it ideal for conduit installations.

What is the purpose of the -CN suffix on this Bently Nevada part?

The -CN suffix specifies the China hazardous area approval package, certifying the cable under NEPSI and CCC safety guidelines.

Which monitoring systems are compatible with this extension cable?

This cable is designed specifically for the 3300 XL NSv Proximity Transducer System and must be used with compatible 3300 NSv probes and 330980 Proximitor sensors.
