Description

The 3500/61-01-CN processed monitoring card provides six independent channels of continuous temperature monitoring and processes inputs from both Resistance Temperature Detector (RTD) and Thermocouple (TC) sensors within a Bently Nevada 3500 Series Machinery Protection System rack. This module samples analog physical inputs, conditions the incoming raw signal waveforms, and executes comparison cycles against user-programmed alert threshold settings. The 3500/61 design incorporates dedicated analog recorder current outputs for each of its six internal channels, enabling real-time telemetry interfacing to parallel instrumentation loops.

Operating within complex distributed machinery networks, the 3500/61-01-CN module type functions natively with the 3500 Rack Configuration Software to configure customized sensor definitions or varied transducer blend profiles. When deployed within a Triple Modular Redundant (TMR) safety block, these temperature modules are slotted adjacent to one another in groups of three, implementing dual-tier voting logic to eliminate single-point failure exposure across machinery networks. This configuration utilizes an RTD/TC non-isolated I/O component featuring internal compression terminations and carries the specific CN localized agency approval option, ensuring field connectivity across industrial rotating machinery bearing hubs.

Features

• Six fully configurable channels supporting mixed processing of Thermocouple and RTD thermal sensor inputs.
• Six dedicated +4 to +20 mA proportional analog recorder outputs providing clean telemetry tracking to external nodes.
• Configurable alarm delays and setpoint notification parameters managed through native rack interface software.
• Hardware support for Triple Modular Redundant (TMR) multi-card voting configurations to enhance plant loop integrity.
• Internal termination design with rugged compression screw terminal blocks to streamline direct field wiring hookups.

Applications

• Continuous bearing radial temperature and stator winding thermal tracking on utility steam and gas propulsion turbines.
• Multi-channel exhaust gas temperature monitoring and high-pressure casing thermal protection across centrifugal process compressors.
• Critical motor and high-capacity industrial pump bearing housing safety interlock monitoring.

Ordering Information

Technical Specifications

Connections/Interfaces

Installation Guidelines

• Rack Slot Sequence: Install the front monitoring processor board into any full-height slot location of the 3500 chassis and affix the internal termination rear I/O module matching it directly on the reverse side of the backplane.
• Shield Grounding Steps: Terminate the outer metal braided shield lines of all field sensor leads cleanly to the nearest chassis ground bus bar on the rack to suppress external electrical noise interferences.
• Lead Wire Balancing: When using long-distance RTD extensions, ensure that matching lead line gauge sizes and wire lengths are used across the 3-wire layout to keep internal loop resistance tracking accurate.
• Electrostatic Prevention: Maintenance staff must remain connected to the equipment ground line with an approved conductive grounding bracelet before pulling, inspecting, or inserting any processor card structures.
