Description

The 3500/91-01-CN is an Ethernet Global Data (EGD) communication gateway module designed for the Bently Nevada 3500 machinery protection system. This module provides comprehensive communication capabilities for transmitting 3500 rack-monitored values, statuses, data values (float), and setpoints (float) over an Ethernet network path. It interfaces directly with EGD protocol compatible controllers to deliver response times suitable for demanding industrial controller applications. The module enables integration via Ethernet UDP/IP frames , processing both producer exchanges and consumer exchanges such as group resets, group trip multiplies, group alarm inhibits, and group special alarm inhibits.

Features

• Provides integration of 3500 rack values with EGD protocol compatible controllers.
• High-speed data transfer via Ethernet UDP/IP protocol.
• Supports EGD version 2.01 protocol.
• Front panel LEDs indicate module operational health (OK LED) and rack communication status ($TX/RX$ LED).
• Accommodates different physical layers including 10BASE-T/100BASE-TX (twisted pair) and 100BASE-FX (fiber optic) via interchangeable I/O modules.

Applications

• Machinery protection and condition monitoring systems.
• Distributed Control System (DCS) and Programmable Logic Controller (PLC) integration.
• Power generation facilities, petrochemical plants, and heavy industrial processing environments requiring real-time machinery asset data.

Ordering Information

Technical Specifications

Connections/Interfaces

Installation Guidelines

• Rack Allocation: Install the main module into one full-height front slot of the 3500 rack. The associated I/O module must be positioned directly behind it in the corresponding full-height rear slot.
• System Requirements: This module requires Version 3.70 or higher of the 3500 Rack Configuration Software for setup.
• Hardware Interfacing: The module must interface with a 3500/22M Transient Data Interface (TDI) utilizing firmware version 1.20 or higher to successfully communicate with individual monitor modules.
• System Constraints: Only one EGD module is permitted per 3500 rack.
• Firmware Requirements: For consumed exchange support, version 2.21 or higher of the 4-Channel firmware is mandatory.

Compliance and Certifications

• FCC: Complies with part 15 of the FCC Rules regarding harmful interference.
• EMC: European Community Directive 2014/30/EU; Standards EN 61000-6-2 (Immunity for Industrial Environments) and EN 61000-6-4 (Emissions for Industrial Environments).
• Electrical Safety: European Community Directive 2014/35/EU (LV Directive) conforming to Standard EN 61010-1.
• RoHS: European Community Directive 2011/65/EU.
• Maritime: DNV GL rules for classification (Ships, offshore units, high speed/light craft) and ABS Rules for Condition of Classification (Part 1, Steel Vessels Rules, Offshore Units and Structures).
• Hazardous Area Approvals: * CNRTLUS: Class I, Zone 2: AEx/Ex nA nC ic IIC T4 Gc; Class I, Zone 2: AEx/Ex ec nC ic IIC T4 Gc; Class I, Division 2, Groups A, B, C, and D; T4 @ Ta = -20 degC to +65 degC when installed per drawing 149243 or 149244.
  • ATEX/IECEx: Ex II 3 G; Ex nA nc ic IIC T4 Gc; Ex ec nc ic IIC T4 Gc; T4 @ Ta = -20 degC to +65 degC when installed per drawing 149243 or 149244.
