The 3500/94M-02-00-CN is an industrial VGA display unit designed for the Bently Nevada 3500 Machinery Protection System. It displays comprehensive asset data and status metrics directly from the machine train, including system event lists, alarm event lists, and detailed channel measurements. By integrating the 3500/94M-02-00-CN within a 19-inch EIA rack structure, operators gain localized or extended access to critical values such as 1X-filtered vibration levels and proximity transducer gap data.
The system relies on high-speed network interfaces to pull real-time monitor status and variables from the rack. Configuration of custom viewing environments is fully supported through the 3500 Rack Configuration Software, enabling users to organize operational data into nine distinct screen designs categorized by machine train groupings. This module communicates touch-control data over dedicated RS232 links and transmits analog RGB and sync information to provide steady industrial display feeds.
The 3500/94M-02-00-CN configuration corresponds to the following verified options from the 3500/94M product series:
| Option Code | Option Description |
|---|---|
| 3500/94M | VGA Display Monitor System (Includes Front VGA Module & Rear I/O Module) |
| -02 | 10-inch display, 19-inch EIA rack mount |
| -00 | KVM Extender and Display Router Box Cables: None |
| -CN / -00 | Agency Approvals: None / Standard Regional Compliance |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes Company) |
| Country of Origin | USA |
| Module Power Consumption | 4.6 W max. |
| Monitor Module Dimensions (H x W x D) | 241.3 mm x 24.4 mm x 241.8 mm (9.5 in x 0.96 in x 9.52 in) |
| Monitor Module Weight | 0.73 kg (1.6 lb.) |
| I/O Module Dimensions (H x W x D) | 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in) |
| I/O Module Weight | 0.34 kg (0.75 lb.) |
| 10-inch Display Dimensions (W x H x D) | 387.4 mm x 248.9 mm x 49.0 mm (15.25 in x 9.8 in x 1.93 in) |
| 10-inch Display Weight | 4.0 kg (8.78 lb) |
| Operating Temperature (Module/I/O) | -20 Celsius to 65 Celsius (-4 Fahrenheit to 149 Fahrenheit) |
| Storage Temperature | -40 Celsius to 85 Celsius (-40 Fahrenheit to 185 Fahrenheit) |
| Humidity Limit | 95%, non-condensing |
| Display Input Voltage (10-inch) | 24 Vdc power supply included (Permissible range 10 Vdc to 28 Vdc) |
| Display Inrush Current | 3.5 A @ 24 V (< 500 microseconds) |
| Display Operating Current | < 500 mA |
| Display Ingress Protection | IP54 dust and water spray protection |
| Rack Space Requirements | 1 full-height front slot (Monitor Module) and 1 full-height rear slot (I/O Module) |
| Connector / Port | Function |
|---|---|
| High-speed network | Interfaces with the system to acquire monitor statuses, values, and channel variables. |
| RS232 port (I/O) | Routes interactive touch controller commands and data between the module and display panel. |
| VGA port (I/O) | Delivers analog red, green, blue, and sync signals to feed the terminal. |
| Front Port | Outbound 24 Vdc power delivery, outbound VGA video stream, and inbound touch data path. |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 3500/94M-02-00-CN
Country of origin:United States
Product Type: VGA Display Modules
Payment: T/T, Western Union
Weight: 1070g
Dimensions: 241.3 mm x 24.4 mm x 241.8 mm
Shipping port: Xiamen
Warranty: 12 months
