Bently Nevada 3500/94M-05-00 3500 Series VGA Display Module

SKU 3500/94M-05-00

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 3500/94M-05-00
  • Origin United States
  • Product Type: VGA Display Modules
  • Payment: T/T, Western Union
  • Weight: 2.5 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3500 VGA Display Modules
Quantità
Call sales Contact

Product Description

Description

Designed for industrial-grade machinery protection and real-time visualization, the 3500/94M-05-00 serves as an integral interface module within the Bently Nevada 3500 Series machinery monitoring rack. This module transmits essential monitoring parameters and configuration data directly to localized display panels, allowing plant operators to view critical vibration levels, phase angles, and alarm statuses on-site without requiring access to a separate control station workstation.

The 3500/94M-05-00 configuration features a 15-inch display formatted for seamless integration into standard 19-inch rack enclosures. It is optimized to deliver consistent, low-latency video feeds directly from the rack backplane. Note that this specific legacy module version has been succeeded by the regional variation 3500/94M-05-00-CN, which serves as a compatible direct replacement depending on localized compliance standards.

Features

  • Provides high-fidelity, real-time VGA visualization of dynamic machinery protection parameters directly at the cabinet level.
  • Includes a 15-inch display unit designed to fit standard industrial 19-inch racks.
  • Option 00 configuration eliminates unnecessary KVM routing cables when integrated into simplified local network structures.
  • Supports multi-channel visualization options for efficient machinery diagnostic overviews.
  • Engineered with rugged hardware components suited for constant operation in harsh industrial environments.

Applications

  • Power generation facilities (monitoring steam and gas turbine systems).
  • Petrochemical and oil refining operations.
  • Heavy industrial processing plants requiring continuous localized cabinet readouts.
  • Compressor and pump protection systems.

Ordering Information

Option Number Configuration Parameter Description Detail
05 Display Size & Mounting 15" display panel with 19" rack mount chassis
00 Cabling Options No KVM extender or display router box cables included

Technical Specifications

Manufacturer Bently Nevada
Part Number/Model 3500/94M-05-00
Series Name 3500 Series Machinery Protection System
Product Type VGA Display Module
Display Size 15 inches
Mounting Type 19-inch standard rack mount
Cabling Option None (Option 00)
Country of Origin United States (USA)
Net Weight 1.07 kg
Shipping Weight 2.50 kg

Installation Guidelines

  • Ensure all power to the 3500 system rack is disconnected before inserting or removing the 3500/94M display module interface card.
  • Install the 15-inch display panel into a standardized 19-inch rack space, utilizing the provided mounting holes to prevent vibration-induced strain.
  • Ensure that cabinet ventilation is sufficient to keep ambient temperatures around the display unit within standard operating limits.
  • Route all VGA and signal interfaces away from high-voltage AC electrical lines to avoid signal interference.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What configuration does the -05-00 suffix represent for the 3500/94M-05-00 module?
The -05 option specifies a 15-inch display with a 19-inch rack mount. The -00 option designates that no KVM extender or display router box cables are included in the package.
Is the 3500/94M-05-00-CN a direct replacement for this model?
Yes, the 3500/94M-05-00-CN model serves as the direct replacement variant, providing equivalent fit, form, and function for the legacy 3500/94M-05-00 module.
What is the physical weight of this display module?
The module has a net physical weight of approximately 1.07 kg, with a gross shipping weight of approximately 2.50 kg.
