Bently Nevada

Bently Nevada 81545-01 3300/20 Transducer I/O and Record Terminals / Dual Epoxy Relays Module

SKU 81545-01

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 81545-01
  • Origin United States
  • Product Type: Transducer I/O Modules
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.35 kg
  • Dimensions: 25 mm x 120 mm x 240 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300/20 Transducer I/O Modules
Quantità
Call sales Contact

Product Description

Description

The GE / Bently Nevada 81545-01 is a Transducer I/O and Record Terminals / Dual Epoxy Relays Module designed for use within the Bently Nevada 3300/20 Dual Thrust Position Monitor system. The 81545-01 provides signal interfacing, transducer input/output connectivity, recorder output connections, and relay contact management for thrust position monitoring applications. It works with the monitor to continuously measure and monitor two independent channels of shaft axial position relative to the axial clearances within rotating machinery, providing early warning of thrust bearing failure.

Features

  • Provides early warning of thrust bearing failure by interfacing axial position signals.
  • Supports continuous measuring and monitoring of two independent channels.
  • Interfaces signal paths for shaft axial position measurement relative to machine axial clearances.
  • Integrates transducer I/O, recorder terminals, and dual epoxy relays on a single rear terminal assembly.

Applications

  • Rotating Machinery Shaft Axial Position Monitoring
  • Thrust Bearing Failure Early Warning Systems
  • Industrial Machinery Protection Systems utilizing Bently Nevada 3300 Series hardware

Technical Specifications

Parameter Value
Manufacturer GE / Bently Nevada
Model Part Number 81545-01
Product Family / System 3300/20
Module Type Transducer I/O and Record Terminals / Dual Epoxy Relays Module

Installation Guidelines

  • Ensure the main 3300 system rack is powered off before inserting or removing the rear terminal module.
  • Verify that transducer field wiring and recorder signal lines are correctly routed to the designated terminal blocks.
  • Ensure proper shield grounding practices are followed for transducer cables to prevent electrical noise interference.
  • Align the module firmly with the rack backplane connectors during installation to ensure proper electrical contact.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the GE / Bently Nevada 81545-01 used for?
The GE / Bently Nevada 81545-01 is a Transducer I/O and Record Terminals / Dual Epoxy Relays Module used to interface field transducers, recorder outputs, and relays for the 3300/20 Dual Thrust Position Monitor.
Which monitor system is the 81545-01 module compatible with?
The module belongs to the Bently Nevada 3300 product family and is specifically designed for use with the 3300/20 Dual Thrust Position Monitor.
How many channels does the 3300/20 system monitor using this module?
The 3300/20 system continuously measures and monitors two independent channels of shaft axial position.
What key machinery measurement does this module support?
It supports shaft axial position measurement relative to internal axial clearances to provide early warning of thrust bearing failure.
