The Bently Nevada 3300/35-12-01-01-00-00 is a 3300 Series Six-Channel Temperature RTD Input Monitor engineered to provide continuous, on-line temperature monitoring for industrial machinery. This specific configuration accepts input signals from six 3-wire 100 ohm platinum RTD sensors across a full-scale range of 0 to 150 degC. It performs continuous signal conditioning, drives individual channel recorder outputs, and includes epoxy-sealed alarm relays for machine protection. Operating within the Bently Nevada 3300 system rack, the unit displays monitored temperatures on a 4-digit LCD screen and provides status indication via front-panel LEDs.
| Ordering Code Component | Selected Option | Technical Specification |
|---|---|---|
| Model | 3300/35 | Six-Channel Temperature RTD Input Monitor |
| A: Full-scale Range | 12 | 0 to 150 degC |
| B: Transducer Input | 01 | 100 ohm platinum (a = 0.00392) (3-wire) |
| C: Alarm Relay | 01 | Epoxy-sealed relays |
| D: Agency Approval | 00 | Not required |
| E: Safety Barriers | 00 | None |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model | 3300/35-12-01-01-00-00 |
| Product Type | Six-Channel Temperature RTD Input Monitor |
| System Compatibility | Bently Nevada 3300 System |
| Number of Channels | 6 independent channels |
| Transducer Type | 3-wire 100 ohm platinum RTD (a = 0.00392) |
| Full-Scale Range | 0 to 150 degC |
| Alarm Relay Module | Epoxy-sealed relays |
| Agency Approval Option | Not required |
| Safety Barrier Option | None |
| Power Consumption | Nominal 4 watts |
| Display | 4-digit 7-segment non-multiplexing LCD with decimal point |
| Display Accuracy (+25 degC) | Within +/-1 degC (+/-1.8 degF) with tenths digit; +/-1.5 degC (+/-2.7 degF) without tenths digit |
| Display Resolution | 0.1 or 1 (user-programmable) |
| LED Status Indicators | OK (green), Alarm 1 (red), Alarm 2 (red), Bypass (red) |
| Recorder Output Signal | User-programmable: +4 to +20 mA, 0 to -10 Vdc, or +1 to +5 Vdc |
| Recorder Accuracy (+4 to +20 mA) | +/-1.8% of signal, +/-0.09 mA offset (at +25 degC) |
| Voltage Output Impedance | 100 ohm (minimum load resistance 10 k ohm) |
| Current Output Compliance | 0 to +12 Vdc across load (0 to 600 ohm load for +4 to +20 mA) |
| Alarm Setpoint Adjustment | Digitally adjustable 0 to +500 degC (0 to +1000 degF), repeatability +/-1 degC (+/-1.8 degF) |
| Operating Temperature | 0 degC to +65 degC (+32 degF to +150 degF) |
| Storage Temperature | -40 degC to +85 degC (-40 degF to +185 degF) |
| Relative Humidity | Up to 95%, non-condensing |
| Space Requirements | Two rack positions (positions 3 through 12 in 3300 rack) |
| Weight | 2.8 kg (6.2 lbs.) |
| Interface / Connector | Function |
|---|---|
| RTD Input Connector | Terminal connections for 3-wire RTD sensor inputs (Channels 1 to 6) |
| Recorder Output Connector | Terminal outputs for individual channel recorder signals (CH1-CH6: +, -S, COM) |
| Alarm Contact Connector | Relay output contacts for Alarm 1 and Alarm 2 (NC, ARM, NO) |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 3300/35-12-01-01-00-00
Country of origin:United States
Product Type: Temperature Monitors
Payment: T/T, Western Union
Weight: 2800g
Dimensions: 241 mm x 50 mm x 280 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
