Description

The 84661-75 is a standard armored interconnect cable designed for use with Bently Nevada High Temperature Velomitor Systems (HTVS), specifically the 330750 and 330752 series. This cable features stainless steel armor protection over a shielded 22 AWG (0.382 mm2) cable, providing mechanical robustness for demanding industrial environments. The 75 indicates a factory-configured length of 75 feet. This interconnect cable is engineered to maintain signal integrity between the HTVS sensor and the monitoring instrumentation. It is equipped with a moisture-resistant female connector at the HTVS transducer end and standard ring lugs at the monitor termination end. The armored design offers increased abrasion resistance, making it suitable for installations where cabling requires protection from physical hazards or heavy industrial activity.

Features

• Standard Armored Interconnect Cable (84661 series)
• Length: 75 feet (factory configured)
• Construction: Stainless steel armor over shielded 22 AWG (0.382 mm2) cable
• Termination: Moisture-resistant female connector (HTVS end) and ring lugs (monitor end)
• Application: Compatible with 330750 and 330752 High Temperature Velomitor Systems
• Temperature Range: -29C to 121C (-20F to 250F)

Applications

• High-temperature machinery vibration monitoring
• Rotating machinery protection in oil and gas, petrochemical, and power generation facilities
• Applications requiring armored cable for abrasion or physical damage protection
• Installation where the sensor is in a high-temperature zone and signal processing electronics are located in a remote, cooler area

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	84661-75	Standard Armored Interconnect Cable
Length (NN)	75	75 feet (22.9 meters approx)

Technical Specifications

Manufacturer	Bently Nevada (Baker Hughes)
Part Number	84661-75
Cable Type	Standard Armored Interconnect Cable
Conductor Size	22 AWG (0.382 mm2)
Shielding	Double-shielded
Armor	Stainless Steel
Connector (HTVS End)	Moisture-resistant female connector
Termination (Monitor End)	Ring lugs
Operating Temperature	-29C to 121C (-20F to 250F)

Installation Guidelines

• Ensure the cable is routed in conduit where possible to provide maximum mechanical protection.
• The moisture-resistant connector at the HTVS end must be securely tightened to maintain seal integrity.
• Maintain a minimum bend radius of 51 mm (2.0 in) to prevent damage to the internal conductors and shielding.
• Secure the cable using appropriate mounting clamps or cable ties, ensuring it is not pulled tight against sharp edges.
• Grounding: Ensure the cable shield is properly terminated at the monitoring system to minimize electromagnetic interference (EMI).
