The C9900-M628 (C9900M628) is a specialized hardware expansion component designed for the C6xxx series of 19-inch slide-in Industrial PCs. This module provides a high-reliability removable frame specifically for 2.5-inch Solid State Drives (SSD), enabling rapid data portability and simplified maintenance for rack-mounted control systems. In data-intensive industrial environments—such as server-based vision inspection, high-speed logging in energy plants, and critical software deployment in pharmaceutical manufacturing—the C9900-M628 allows for the hot-swapping or secure removal of storage media without disassembling the entire PC chassis. This functionality is essential for minimizing system downtime during storage upgrades or ensuring data security through the physical removal of sensitive information during machine transport or maintenance.
The C9900-M628 features a robust mechanical design optimized for the high-vibration and thermal demands of 19-inch rack installations. The frame is engineered to house standard 2.5-inch industrial SSDs, utilizing high-cycle connectors designed for repeated insertion and removal. The integration into the host Industrial PC is seamless, providing a vibration-proof locking mechanism that ensures consistent electrical contact even in heavy-duty manufacturing environments. This slide-in frame architecture facilitates high-speed SATA data transfer rates while maintaining the structural integrity and cooling efficiency of the primary Industrial PC housing.
| Feature | Specification |
| Model | C9900-M628 |
| Brand | BECKHOFF |
| Device Type | Removable Frame / Mobile Rack |
| Supported Drive | 2.5-inch SSD (Solid State Drive) |
| Compatibility | 19-inch slide-in Industrial PCs (C6xxx series) |
| Mounting | Front-accessible or internal slide-in slot |
| Material | Industrial Grade Metal / Composite |
| Origin | Germany |
| Weight | Approx. 0.5 kg |
| Shipping Weight | 3.0 kg |
Does the C9900-M628 support "Hot-Swapping" while the OS is running?
Hot-swap capability depends on the host PC's BIOS settings and the operating system's AHCI configuration. While the hardware frame is designed for removal, the software must be configured to unmount the drive to prevent data corruption. Always verify that the "Removable" bit is set in the TwinCAT or Windows storage controller settings.
Is this frame compatible with traditional mechanical Hard Disk Drives (HDD)?
The C9900-M628 is specifically optimized for 2.5-inch SSDs. While some HDDs of the same form factor may physically fit, SSDs are strongly recommended for industrial slide-in PCs due to their superior resistance to shock, vibration, and higher operating temperature ranges.
What is the benefit of a removable frame in a 19-inch rack system?
In a 19-inch rack environment, space is limited and rear access is often restricted. The C9900-M628 allows maintenance personnel to replace a failed drive or perform a full system backup from the front panel, significantly reducing the labor and time required for storage-related service tasks.
Secure Mounting: When installing the SSD into the C9900-M628 frame, ensure all mounting screws are tightened to provide a low-impedance thermal path. The frame acts as a secondary heat sink for the SSD; improper mounting can lead to thermal throttling during high-speed write operations.
Connector Care: Although designed for high durability, ensure the slide-in slot is free of dust and debris before insertion. In environments with high airborne particulates, use compressed air to clean the backplane connector periodically to maintain signal integrity for SATA 6.0 Gb/s communication.
Vibration Protection: Ensure the front locking handle or screw is fully engaged after insertion. The 19-inch rack environment can subject the PC to harmonic vibrations; a loose frame can cause intermittent communication errors or "Disk Not Found" boot failures.
Global Express Shipping
Returns & Warranty
Manufacturer: BECKHOFF
Product No.: C9900-M628
Country of origin:Germany
Product Type: 19-inch slide-in Industrial PC
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
