The 060G2420 (060G2420) is a high-precision pressure transmitter engineered for industrial applications requiring a Flush Diaphragm interface. This design is critical for measuring the pressure of high-viscosity, crystallizing, or contaminated media in sectors such as food and beverage processing, wastewater treatment, and chemical manufacturing. With a low-pressure range of 0 to 0.6 bar, the 060G2420 delivers an industry-leading typical accuracy of 0.2% FS, ensuring tight process control and preventing costly material waste. Its ATEX approval permits safe operation in potentially explosive atmospheres, making it a reliable solution for monitoring tank levels or pipeline pressures in hazardous industrial zones.
The 060G2420 utilizes a piezoresistive sensing element protected by a robust flush-mounted diaphragm. This configuration prevents media build-up and clogging, which often plague standard pressure ports in "dirty" processes. The transmitter outputs a standard 4-20 mA analog signal, featuring a low clipping level of 3.6 mA and a high clipping level of 22.4 mA for advanced diagnostic capabilities. Encased in an IP65 rated housing with an EN 175301-803-A (DIN-plug) electrical connection, the device is designed for rapid installation and resistance to mechanical vibration. The internal electronics are temperature-compensated between 0 to 80 deg C to maintain signal integrity despite ambient thermal fluctuations.
| Attribute | Specification |
| Model | 060G2420 |
| Brand | Danfoss |
| Pressure Range | 0 to 0.6 bar (0 to 60 kPa) |
| Output Signal | 4 - 20 mA (Current) |
| Accuracy (Typical) | 0.2 % FS |
| Diaphragm Type | Flush Diaphragm |
| Electrical Connection | DIN-plug (EN 175301-803-A) |
| Enclosure Rating | IP65 |
| Supply Voltage | 9 - 32 VDC |
| Operating Temp | -10 to 85 deg C |
| Overload Pressure | 2 bar (Max) |
| Approval | ATEX |
| Net Weight | 0.344 kg |
Why is the flush diaphragm essential for this specific model?
The flush diaphragm eliminates the "pressure cavity" found in standard sensors. This prevents thick or particulate-heavy fluids (like pulp, sludge, or adhesives) from hardening inside the sensor port, which would otherwise lead to drift or total sensor failure.
Does the 060G2420 require a separate safety barrier for ATEX zones?
Yes. While this unit carries ATEX approval for hazardous areas, it must be installed in conjunction with a certified intrinsically safe barrier or zener barrier if the specific zone classification requires limited energy spark protection.
What is the significance of the 4 ms response time?
A 4 ms response time allows the transmitter to detect rapid pressure spikes or "water hammer" effects in pipelines. This high-speed feedback is vital for automated safety systems to trigger emergency shut-off valves and protect downstream equipment.
Sealing and Torque: When installing the 41 mm HEX pressure connection, ensure the sealing gasket is compatible with the process media. Use a calibrated torque wrench to avoid over-tightening, which can distort the flush diaphragm and cause a zero-point shift.
Cleaning Protocol: Because the diaphragm is exposed, never use sharp objects (like screwdrivers or wire brushes) to clean the sensor face. Use a soft cloth and a compatible solvent to prevent scratching the thin metallic membrane, which could compromise accuracy and corrosion resistance.
Wiring for Noise Immunity: In environments with high electromagnetic interference (EMI)—such as near large VFDs or motors—use twisted-pair shielded cable for the 4-20 mA loop. The shield should be grounded at the PLC/Controller side only to prevent ground loops that could distort the 0.2% accuracy performance.
Global Express Shipping
Returns & Warranty
Manufacturer: Danfoss
Product No.: 060G2420
Country of origin:Denmark
Product Type: Pressure Transmitter
Payment: T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months
