Foxboro

Foxboro P0916NK 9 Pin HDLC Base-To-Base Cable

SKU P0916NK

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Foxboro
  • Product No.: P0916NK
  • Origin France
  • Product Type: Cable Assemblies
  • Payment: T/T, Western Union
  • Weight: 0.15 kg
  • Dimensions: 133 mm x 30 mm x 30 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Cable Assemblies Foxboro I/A Series
Quantità
Call sales Contact

Product Description

Description

The Foxboro P0916NK is a High-Level Data Link Control (HDLC) base-to-base communication cable used for interconnecting system baseplates within Foxboro industrial control systems. The P0916NK facilitates data transfer across hardware bases, providing dedicated physical signal connections between system nodes. Featuring a 9-pin male to 9-pin male connector configuration, this assembly establishes point-to-point serial communication links across a compact 5-1/4 inch length.

Features

  • HDLC communication support for base-to-base system links
  • Dual 9-pin male connector configuration
  • Compact 5-1/4 inch cable length

Applications

  • Interconnecting adjacent Foxboro system baseplates
  • Base-to-base HDLC communication links in process control architectures

Technical Specifications

Parameter Specification
Manufacturer Foxboro
Part Number P0916NK
Cable Type HDLC Base-To-Base Cable
Connector A 9 Pin Male
Connector B 9 Pin Male
Cable Length 5-1/4 inch

Connections/Interfaces

Connector Pin Function
9-Pin Male (Side A) HDLC Base Connection A
9-Pin Male (Side B) HDLC Base Connection B

Installation Guidelines

  • Ensure system power is disconnected or appropriate bus maintenance procedures are followed before connecting or disconnecting the cable.
  • Secure both 9-pin male connectors firmly to the corresponding mating baseplate receptacles to ensure reliable contact and grounding continuity.
  • Avoid excessive bending, twisting, or strain on the short 5-1/4 inch cable assembly during routing between baseplates.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the Foxboro P0916NK used for?
The Foxboro P0916NK is an HDLC base-to-base cable used to establish communication connections between system baseplates.
What are the connector types on the P0916NK cable?
The cable features 9-pin male connectors on both ends.
What is the length of the device?
The cable has a length of 5-1/4 inches.
