The GE IS220PVIBH1AL provides a high-integrity electrical interface between redundant Ethernet control networks and a specialized vibration terminal board. This vibration monitor I/O pack captures, digitizes, and processes high-speed dynamic signals from proximity probes, seismic transducers, and accelerometers to monitor machine health and enforce protective trip loops. Integrated into the Mark VIe control series architecture, the pack performs localized signal conditioning and spectrum calculations before distributing raw data matrix fields and diagnostic parameters over dual 10/100 Mbps communication links to the primary processors, ensuring real-time machinery protection for critical rotating assets.
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model Number | IS220PVIBH1AL |
| System Series | Mark VIe Control System |
| Product Type | Vibration Monitor I/O Pack |
| Country of Origin | USA |
| Network Interface | Dual 10/100 Base-T Ethernet ports (ENET1 / ENET2) |
| Signal Input Types | Proximity probes, Seismic transducers, Accelerometers |
| Ambient Operating Temperature | -30 degC to +65 degC |
| Storage Temperature Range | -40 degC to +85 degC |
| Cooling | Natural convection ventilation |
| Interface Port | Function |
|---|---|
| High-Density Connector | Direct mechanical plug matching the base TVIB terminal board interface |
| ENET1 | Primary RJ45 Ethernet link for connection to the active control network |
| ENET2 | Secondary RJ45 Ethernet link for independent network path redundancy |
| Chassis Ground | Hardware grounding terminal for EMI shielding and electrical isolation |
Align the high-density male pin matrix on the underside of the module with the receptor socket located on the TVIB terminal board. Press down firmly to seat the electrical connections completely, then tighten the integrated mechanical retention hardware to prevent displacement from continuous turbine deck vibration.
Insert individual category-rated industrial Ethernet patch cables into both the ENET1 and ENET2 ports. Route these communication paths through separated internal wiring ducts to isolate the data buses from high-voltage motor starter lines and minimize inductive noise interference.
The internal power rails contain soft-start current suppression circuits. This allows maintenance engineers to remove or insert the module while the underlying terminal block assembly remains fully energized, minimizing down-time during essential service windows.
Global Express Shipping
Returns & Warranty
Manufacturer: General Electric
Product No.: IS220PVIBH1AL
Country of origin:United States
Product Type: Vibration Monitor I/O Pack
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 380g
Dimensions: 6cm x 13cm x 8.3cm
Shipping port: Xiamen
Warranty: 12 months
